SPECIFICATIONS:
- Unsurpassed quality – fully automated manufacturing and direct-bonding technology ensure tag reliability
- Optimum operation – the highest out-of-box performance ratings in the industry, with no line-of-sight requirements
- Practically limitless options – choose from a broad range of standard sizes and integrated chips, or customize to fit any application
TECHNICAL FEATURES:
- ISO 11784 and 11785 compliant FDX-B or FDX-A
- Multiple IC options, including EM4305, Hitag S, FDX, or HDX
- Bioglass capsules with parylene coating ensure optimal biocompatibility
- Unlimited resistance to water and chemical absorption
- Memory storage up to 2048 bits
- Custom sizes and programming available
TECHNICAL PARAMETER:
Product Code |
KD134-8RW |
|
Electronic |
Operating Frequency |
134.2 kHz |
Chip Type |
EM4305 |
|
Memory |
512 bit EEPROM |
|
Reading Distance |
Dependent upon reader, environment and application |
|
Physical |
Dimensions |
Φ2.12 x 8.5 mm |
Tagging Method |
Subcutaneous |
|
Housing Material |
Bio-glass |
|
Chemical and Mechanical |
Water |
IP68, 68° F (20° C), 3.3 ft (1 m) x 24 h |
Withstands Exposure To |
Alcohol, ammonium chloride 25%, fuel B, HCL 10%, salt water |
|
Environmental Test Conditions |
68° F (20° C), 100 h |
|
Vibration |
IEC 68.2.6 [10 g, 10 to 2000 Hz, 3 axis, 2.5 h] |
|
Shock |
IEC 68.2.29 [40 g, 18ms, 6 axis, 2000 times] |
|
Thermal |
Storage: |
-40° to +194° F (-40° to +90° C), 1000 h |
Operating |
-13 °to +185° F (-25° to +85° C) |
|
Peak |
248° F (120° C), 100 h; 284° F (140° C), 10 h |
|
Other |
Standards |
ISO 11784, ISO 11785 |
Options |
Parylene coating (when ordering coating, increase base model number by one), custom programming |
|
Warranty |
2 Years |
|
What is RFID Microchip?
Radio Frequency Identification
RFID Microchip also known as a transponder, is about a size of a grain of rice. The transponder which is coded with a permanent code, is implanted under the animal's skin for identification purpose. Using Radio Frequency, the animal can be identified by using a RFID scanner.
What are the benefits
- Unique identity for every livestock and pet.
- Import and export control.
- Lost pet can be easily traced back to it's owner.
- Veterinarians are able to keep the animal's heath record.
- Easily implanted and no impact on the animal.
- Suitable for use in extreme conditions.
- Coupled with software, the RFID tag is a must inmanagement of animals, either livestock or household pet.
Why are our Microchips much cheaper?
- Factory strategically located.
- Direct from our factory.
- Sophisticated cost savings production process.
How we deliver superior quality Microchips?
- Equipment and Machines imported from Germany, Japan, USA etc.
- Strict quality control.
- Microchip tested and inspected individually.
- Use only top quality material to manufacture microchips.
Why use ICAR (International Committee for Animals Recording) Approved Microchips?
- Specially designed for animals.
- Superior quality.
- Strict manufacturing guidelines.
- Safe for use for a wide range of animals.
- Readable by all ISO 11784/11785 tag readers.
- Unique identification globally.
- Encased in bio-compatible glass capsule.
- Microchip will not migrate once implanted.
