Help CenterHigh Speed Steel Coil Slitting Line
Related Products
I. Introduction of the metal slitting line:
Slitting line machine is not only for the steel service cutting industry, but also for the pipe industry. A lot of customers make the pipes before slitting the large coil to the small size of coils.
This series of slitting line is used for slitting coils into required width through the procedure of uncoiling, slitting and recoiling.
This automatic coil slitting line is a integration of mechanical, electrical, hydraulic and pneumatic technology. It is easy to operate, and has high production efficiency. It is capable of processing CR coils, silicon steel coils, stainless coils, and colored or plated coils. Thickness are such as 0.3~2, 0.5~3, 1~6, 2~8, 3~12, 6-16mm, etc.
II. Consist of the metal slitting machine:
1. Coil car
2. De-coiler
3. Peeler entry table
4. Straightening unit
5. Shearing machine
6. Loop table
7. Coil guide and pinch roll
8. Slitting machine
9. Scrap winder (both sides)
10. Loop table
11. Separator and tension table
12. Deflector roll and exit threading table
13. Re-coiler
14. Over arm separator in the re-coiler.
15. Exit coil car for re-coiler
16. Hydraulic system
17. Pneumatic system
18. Electrical control system
III. Specification of automatic sheet slitting line:
1. High speed
2. PLC control
3. Good quality, competitive price
4. Easy and safe operation
