Aspera Freezer Compressor,R134a, EMT6170Z/EMS6170Z

Specifications

They are the best selling high-tech compressors sold in the world. They are ideal for domestic refrigeration and also for small

Aspera Freezer/Refrigerator Compressor :



They are the best selling high-tech compressors sold in the world. They are ideal for domestic refrigeration and also for small commercial applications. They are small, have low noise and vibration levels, they achieve the highest levels of efficiency available in the market for this category.



Discription:



Refrigerant:	R-134a	Displacement (cm³):	7,69
Voltage:	220-240 V 50 Hz 1 ~	Lubricant Type:	ISO22
Frequency (Hz):	50	Lubricant Charge (ml):	180
Application:	HBP	Motor Type:	CSIR
HP:	1/3-	Starting Torque:	HST
Efficiency:	1,88	Type of Test:	EN12900HH
Capacity:	628





External Features:



Shape	Material	Diameter (mm)
Suction Connector	Slanted 42°	Copper	6,10
Discharge Connector	Straight	Copper	4,86
Process Connector	Slanted 42°	Copper	6,10



Oil Cooler:
Base Plate:	European Standard
Tray Holder:	No
Weight (kg):	7,80





Application



Maximum ambient temperature (ºC):	43
Expansion device:	Capillary/ Valve
Cooling:	Fan Cooling
Air flow rate:





Mechanical Data



Bill of materials:	194RA67
Starting torque:	High Starting Torque
Bore (mm):	24,00
Stroke (mm):	8,50
Weight (kg):	7,80





Electrical Data



Motor type:	CSIR
Winding Resistance (25ºC) - Start:	0,00
Winding Resistance (25ºC) - Run:	0,00





 Stocks Always Available:





Refrigerant R134a Medium/High Back Pressure
EMT45HDR	1/6HP
EMT6170Z	1/3HP
EM65HHR	1/4HP
NE6170Z	1/3HP
NE6187Z	3/8HP
NEK6212Z	1/2HP
NEK6214Z	3/4HP
T6215Z	3/4HP
NJ6220Z	1HP
NJ6226Z	1.25HP
Refrigerant R134a Low Back Pressure
EMT45HLR	1/6HP
EMT55HLR	1/5HP
EMT65HLR	1/4HP
FF7.5HAK	1/3HP
FF10HAK	7/16HP
FF8.5HBK	1/3HP
FFI 12HBK	1/2HP
NB1118Z	1/3HP
NE1121Z	7/16HP
NE1130Z	1/2HP
NE2130Z	1/2HP
NE2134Z	9/16HP
NE2140Z	3/4HP
