Embraco Aspera Refrigerator Compressor R22,HBP, NJ9226E
Negotiable
MOQ: 100 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Compressor
Place of Origin:
China
Brand Name:
Embraco Aspera
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen/Hong Kong/Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Aspera Embraco Refrigeration Compressor R22,HBP, T6220ENegotiableMOQ: 100 Units -
Embraco/Aspera Compressors on Sale R22,HBP, NE9213ENegotiableMOQ: 100 Units
-
Embraco Aspera Freezer Compressor R22,HBP, NE6211ENegotiableMOQ: 100 Units
-
Embraco Aspera R22 Freezer Compressor NE6210ENegotiableMOQ: 100 Units
-
Embraco Aspera Compressor R22,LBP, NJ2190ENegotiableMOQ: 100 Units
Type
Compressor
Place of Origin
China
Brand Name
Embraco Aspera
Model Number
NJ9226E
Certification
CE, ROHS, UL
After-sales Service Provided
Overseas third-party support available
Specifications
The Embraco NE series of compressors has two efficiency levels and is designed especially for commercial use.The Embraco NE series of compressors has two efficiency levels and is designed especially for commercial use. Compatible with variable speed technology VNEK version, it presents models that are also available in versions with high or low starting torque.
Discription:
| Refrigerant: | R-22 | Displacement (cm³): | 21,71 |
| Voltage: | 208-230 V 60 Hz 1~ | Lubricant Type: | ISO46 |
| Frequency (Hz): | 50 | Lubricant Charge (ml): | 750 |
| Application: | M/HBP | Motor Type: | CSCR |
| HP: | 1+ | Starting Torque: | HST |
| Efficiency: | 2,13 | Type of Test: | ASHRAE46 |
| Capacity: | 2.616 |
External Features:
| Shape | Material | Diameter (mm) | |
| Suction Connector | Vertical | Copper | 12,77 |
| Discharge Connector | Slanted J | Copper | 8,00 |
| Process Connector | Vertical | Copper | 6,42 |
| Oil Cooler: | |
| Base Plate: | American Standard |
| Tray Holder: | No |
| Weight (kg): | 20,53 |
Application
| Maximum ambient temperature (ºC): | 43 |
| Expansion device: | Capillary/ Valve |
| Cooling: | Fan Cooling |
| Air flow rate: |
Mechanical Data
| Bill of materials: | 144ID12 |
| Starting torque: | High Starting Torque |
| Bore (mm): | 38,09 |
| Stroke (mm): | 9,53 |
| Weight (kg): | 20,53 |
Electrical Data
| Motor type: | CSCR |
| Winding Resistance (25ºC) - Start: | 7,76 |
| Winding Resistance (25ºC) - Run: | 1,78 |
Stocks Always Available:
| Refrigerant R22 Low Back Pressure | |
| Item | Horse Power |
| NE2134E | 9/16HP |
| T2140E | 3/4HP |
| T2155E | 1HP |
| T2168E | 1.25HP |
| NJ2190E | 1.5HP |
| Refrigerant R22 High/Medium Back Pressure | |
| NB6152E | 1/4HP |
| NB6165E | 1/3HP |
| NE6210E | 3/8HP |
| NE6211E | 1/2HP |
| NE9213E | 9/16HP |
| T6220E | 3/4HP |
| NJ9266E | 1HP |
| NJ9232E | 1.5HP |
| NJ9238E | 1.75HP |
