Home > Products > Reciprocating Compressor > Maneurop reciprocating compressor MTZ22
Maneurop reciprocating compressor MTZ22
- 2000 Unit / Units per Month
- Guangzhou/Shenzhen/Hongkong
- Credit Card
Product Details
Place of Origin: | China | Brand Name: | Maneurop | Model Number: | MTZ22 |
Type: | Refrigeration Compressor | Application: | Refrigeration Parts | Certification: | CE |
Product Description
Maneurop reciprocating compressor MTZ22
- MT and MTZ series compressors are of the hermetic reciprocating type and are designed for medium and high evaporating temperature applications.
- The positive benefits of internal motor protection, high efficiency circular valve design and high torque motors provide for a quality installation.
- MT and MTZ compressors have a large internal free volume that protects against the risk of liquid hammering when liquid refrigerant enters the compressor.
- MT and MTZ compressors are fully suction-gas cooled. This means that no additional compressor cooling is required and allows the compressors to be insulated with acoustic jackets, to obtain lower sound levels, without the risk of compressor overheating.
-
Specification Maneurop reciprocating compressor MTZ22 Capacity(Btu/hr) 5021 Power(W) 1857 C.O.P(Btu/Wh) 2.7 Mass flow(Kg/h) 113 Weight (Kg) 21 Refrigerant R404A,R134A,etc. Approval CE,UL
Maneurop compressor MTZ22 Features
Danfoss focuses on enhancing comfort, efficiency, and sustainability for residential, light commercial, commercial and industrial applications with:
- The widest product range in inverter technology: from 3 to 26TR, there is always a Danfoss prequalified compressor and drive available to provide stunning efficiency
- Excellent energy efficiency across the complete scroll range, offering performance that ranks among the best in the market
- Low ODP refrigerants with a complete compressor range using R410A
- Compact solutions for smaller footprints
- Reduced sound levels, for greater comfort in residential, commercial areas.
- In addition, our clients can benefit from a large number of innovations and patents including:
- A 40-ton compressor with integrated electronics and remote control and diagnostics, for improved motor protection
- Reduced installation costs with fast connections thanks to pre-equipped compressors for different manifold configurations.
Model | Cooling Capacity | Input | Current | COP | Displacement | Oil charge | Weight | Height | Voltage |
(W) | (W) | (A) | (W/W) | (m3/h) | (dm³) | (kg) | (mm) | ||
MTZ18-4VM | 2553 | 989 | 2.19 | 2.58 | 5.3 | 0.95 | 21 | 356 | 380V,50Hz |
MTZ22-4VM | 5021 | 1857 | 3.47 | 2.7 | 6.63 | 0.95 | 21 | 356 | 380V,50Hz |
MTZ28-4VM | 6536 | 2361 | 4.57 | 2.77 | 8.36 | 0.95 | 23 | 356 | 380V,50Hz |
MTZ32-4VM | 7335 | 2665 | 4.9 | 2.76 | 9.37 | 0.95 | 24 | 356 | 380V,50Hz |
MTZ36-4VM | 8283 | 3206 | 5.99 | 2.58 | 10.52 | 0.95 | 25 | 356 | 380V,50Hz |
MTZ40-4VM | 9582 | 3712 | 6.92 | 2.58 | 11.81 | 0.95 | 26 | 356 | 380V,50Hz |
MTZ44-4VM | 10096 | 3376 | 6.18 | 2.99 | 13.26 | 1.8 | 37 | 415 | 380V,50Hz |
MTZ50-4VM | 11531 | 4007 | 6.95 | 2.88 | 14.9 | 1.8 | 37 | 415 | 380V,50Hz |
MTZ56-4VM | 12999 | 4367 | 7.91 | 2.98 | 16.73 | 1.8 | 39 | 415 | 380V,50Hz |
MTZ64-4VM | 14851 | 5016 | 8.91 | 2.96 | 18.74 | 1.8 | 39 | 415 | 380V,50Hz |
MTZ72-4VM | 17047 | 5873 | 10.48 | 2.9 | 21.04 | 1.8 | 40 | 415 | 380V,50Hz |
MTZ80-4VM | 19333 | 6825 | 12.08 | 2.83 | 23.63 | 1.8 | 40 | 415 | 380V,50Hz |
MTZ100-4VM | 22699 | 7997 | 13.83 | 2.84 | 29.8 | 3.9 | 60 | 540 | 380V,50Hz |
MTZ125-4VM | 29788 | 10325 | 16.28 | 2.89 | 37.49 | 3.9 | 64 | 540 | 380V,50Hz |
MTZ144-4VM | 33067 | 11586 | 18.8 | 2.85 | 42.09 | 3.9 | 67 | 540 | 380V,50Hz |
MTZ166-4VM | 37819 | 13457 | 21.5 | 2.81 | 47.06 | 3.9 | 67 | 540 | 380V,50Hz |
1. How long have you been in this field? Where is your company?
We have been in this field for years and we are located in Guangzhou, the capital city of Guangdong Province, near to Shenzhen, Hong Kong, very convenient for shipping.
2. Can you offer us at the best price?
Of course, we always take good care of our clients if both are sincere to establish good relationship.
3. How about the MOQ?
1 unit is ok
4. Shipping methods and lead time?
By Express: 3-5 working days to your door (DHL, UPS, TNT, FedEx...)
By Air: 5-8 working days to your airport
By Sea: Pls advise your port of destination, the exact days will be confirmed by our forwarders,
And the following lead time is for your reference.
Europe and America (25 - 35 days), Asia (3-7 days), Australia (16-23 days)
5. What is the term of Payment?
T/T, L/C, Western Union;
30% T/T in advance, 70% before delivery.
6. Packaging & Shipping:
Packing: PALLET, wooden case or with outer carton, or as per customers' specific requirements.
7. Cooperate Partners:
Copeland, Maneurop, Performer, Blitzer, Danfoss, Sanyo, Daikin, Toshiba GMCC, Hitachi Highly, Embraco,
Mitshubishi, SECOP, etc.
