MT/MTZ Reciprocating • R22 R417A R407C R134a R404A/R507
Maneurop reciprocating compressors from Danfoss Commercial Compressors are specially designed for applications with a wide range of operating conditions.All components are of high quality and precision in order to assure a long product life.
Maneurop MT and MTZ series compressors are of the hermetic reciprocating type and are designed for medium and high evaporating temperature applications.
The positive benefits of internal motor protection,high efficiency circular valve design and high torque motors provide for a quality installation.
MT&MTZ have the same mechanical and motor design.
MT is charged with mineral oil while MTZ with polyester oil.
These compressor ranges can be used with a large choice of refrigerants according their compatibility with the oil.
(MTZ125-4VM)Maneurop Reciprocating Compressor MT and MTZ Compressors
MTZ compressors can be used in new installations and also to replace Maneurop MTE compressors in existing installations.
MT and MTZ compressors have a large internal free volume thay protects against the risk of liquid hammering when liquid refrigerant enters the compressor.
MT and MTZ compressors are fully suction-gas cooled.This means that no additional compressor cooling is required with acoustic jackets,to obtain lower sound levels,without the risk of compressor overheating.
MT and MTZ compressors are available in 16 different models with displacement ranging from 30 to 271 cm³/rev.Seven different motor voltage ranges are availablefor single and three phase power supplies at 50 and 60 Hz.All compressors are available in VE version(oil equalisation + oil sight glass).
| Technical specifications | |||||||||||||
| Model | Displacement | Cyl. Number | Oil charge dm³ | Net weight kg | Available motor voltage codes | ||||||||
| Code | cm³/rev | m³/h at 2900 rpm | 1 | 3 | 4 | 5 | 6 | 7 | 9 | ||||
| MT/MTZ018 | JA | 30.23 | 5.26 | 1 | 0.95 | 21 | * | * | * | * | - | - | - |
| MT/MTZ022 | JC | 38.12 | 6.63 | 1 | 0.95 | 21 | * | * | * | * | * | - | * |
| MT/MTZ028 | JE | 48.06 | 8.36 | 1 | 0.95 | 23 | * | * | * | * | * | - | * |
| MT/MTZ032 | JF | 53.86 | 9.37 | 1 | 0.95 | 24 | * | * | * | * | * | o | * |
| MT/MTZ036 | JG | 60.47 | 10.52 | 1 | 0.95 | 25 | * | * | * | * | * | o | * |
| MT/MTZ040 | JH | 67.89 | 11.81 | 1 | 0.95 | 26 | * | * | * | - | * | - | - |
| MT/MTZ044 | HJ | 76.22 | 13.26 | 2 | 1.8 | 35 | * | * | * | - | * | * | * |
| MT/MTZ050 | HK | 85.64 | 14.9 | 2 | 1.8 | 35 | * | * | * | - | * | * | * |
| MT/MTZ056 | HL | 96.13 | 16.73 | 2 | 1.8 | 37 | * | * | * | - | * | * | * |
| MT/MTZ064 | HM | 107.71 | 18.74 | 2 | 1.8 | 37 | * | * | * | - | * | - | * |
| MT/MTZ072 | HN | 120.94 | 21.04 | 2 | 1.8 | 40 | - | * | * | - | * | - | * |
| MT/MTZ080 | HP | 135.78 | 23.63 | 2 | 1.8 | 40 | - | * | * | - | * | - | * |
| MT/MTZ100 | HS | 171.26 | 29.8 | 4 | 3.9 | 60 | - | * | * | - | * | * | * |
| MT/MTZ125 | HU | 215.44 | 37.49 | 4 | 3.9 | 64 | - | * | * | - | * | * | * |
| MT/MTZ144 | HV | 241.87 | 42.09 | 4 | 3.9 | 67 | - | * | * | - | * | * | * |
| MT/MTZ160 | HW | 271.55 | 47.25 | 4 | 3.9 | 67 | - | * | * | - | * | * | * |
| * Available in MT and MTZ o Available in MTZ only | |||||||||||||
