Specifications
hydraulic 120ton punch and shear machine1.Laser position
2.Auto holding device
3.Auto temperature cooling
4.avoi
IN STOCK KRRASS Q35Y 16 20 25 30 Series Shearing and Punching Machine punch and shear machine,Q35Y 90ton ironwork machine,taiwan 120ton, 160ton, 200ton 65 ton hydraulic ironworker machine, 120ton punch and shear machine
universal hydraulic iron work hydraulic iron work hydraulic steel bar cutting machine hydraulic
Company Information
Q35Y Series hydraulic combined punching&shearing machine can cut and punch
all kinds of materials such as plate, square bar, angle, round bar, channel and so on.
KRRASS Industrial hydraulic ironworkers have been designed and built to the highest quality standards in the industry.
This profitable machine will serve any grueling fabrication shop for decades to come.
This machine is typically in stock for quick deliveries.
1. hydraulic turkey ironworker machine Punching
Full range of universal punches and dies are hydraulic ironworker available.unique style allows for large angle iron punching and large channel
punching.Large viewing window on stripper swing away design for ease of operation.large two piece gauging table
with rulers and stop as standard fittings.Quick change coupling nut and sleeve for rapid replacement of change.
2. hydraulic turkey ironworker machine Shearing
Round and square bar shear has multiple holes for a variety of sizes. Adjustable hold down device for round/square bar,
channel/beam cutting. Large strong guarding for max safety. The angle shear has the ability to cut angle at 45°both top and bottom leg. This gives the operator the ability to make a picture frame corner for perfect welds.
Diamond shaped blade for quality cuts that is minimal material lost and deformity. Easily adjustable hold-down device for accurate plate cutting.
Large 15″squaring arm with inlaid scale.Special anti-distorted blade for quality cutting.Lower blade has four usable edges.There is screw allow for gap adjust no shim needed.
3. hydraulic turkey ironworker machine Notching
Unique design allows for cutting of angle and flat bar. Electrical interlock safety guard and three gauging stops for
precise positioning.The notching section of this hydraulic ironworker is perfect for notching out metal plate,
angle iron and much more. The notching station also has an oversized table with material stops.
This section of the machine can also be outfitted with the optional vee notcher.
4. hydraulic turkey ironworker machine Bending
Also bend the plate below 500mm. All the components of Machine are of the highest quality in their safty,
function, capability and maintenance
hydraulic turkey ironworker machine Technical feature:
Model |
Q35Y-16 |
Q35Y-20 |
Q35Y-25 |
Q35Y-30 |
Q35Y-35 |
Q35Y-40 |
Q35Y-50 |
Q35Y-60 |
Working Pressure(Ton) |
55 |
75 |
110 |
140 |
175 |
200 |
250 |
300 |
Max. Cutting Thickness (mm) |
16 |
20 |
25 |
26 |
30 |
35 |
40 |
45 |
Plate Strength (N/mm2) |
lower than 450 |
lower than 450 |
lower than 450 |
lower than 450 |
lower than 450 |
lower than 450 |
lower than 450 |
lower than 450 |
Shear Angle (degree) |
7 |
8 |
8 |
8 |
8 |
8 |
8 |
8 |
Shearing Size Of One Stroke T*W(mm) |
16*250 8*400 |
20*330 10*480 |
25*330 16*600 |
26*330 20*600 |
30*400 20*600 |
35*400 25*700 |
40*400 30*750 |
45*400 30*800 |
Ram Stroke (mm) |
80 |
80 |
80 |
80 |
80 |
100 |
100 |
100 |
Stroke Times (per minute) |
8 |
8 |
8 |
8 |
8 |
8 |
8 |
8 |
Throat Depth (mm) |
300 |
355 |
400 |
600 |
600 |
600 |
600 |
600 |
Punching Thickness (mm) |
16 |
20 |
25 |
26 |
28 |
35 |
40 |
40 |
Max. Punching Diameter (mm) |
25 |
30 |
35 |
38 |
40 |
40 |
40 |
45 |
Power Of Main Motor (kw) |
4 |
5.5 |
7.5 |
11 |
11 |
15 |
18 |
18 |
Overall Dimensions L*W*H (mm) |
1640*730*1770 |
1860*800*1990 |
2355*960*2090 |
2680*1040*2300 |
2720*1080*2400 |
2770*1240*2450 |
3000*1440*2480 |
3050*1550*2500 |
Weight Of Machine (kg) |
1770 |
2200 |
4800 |
6200 |
7000 |
9200 |
12800 |
13500 |
combined turkey ironworker machine photos with different colors:
WELECOME DO FACTORY INSPECTION for hydraulic iron work machine:
Notes: please choose the model you want to use, then we can give you a quote asap.
