full color P10 outdoor led display screen video hot free video play led screen for sale
- 10000 Square Meter / Square Meters per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Guangdong, China | Brand Name: | JC | Model Number: | JC-FSO-PH10MM |
Usage: | Outdoor | Tube Chip Color: | Full Color | Display Function: | Video |
Pixels: | Other, indoor electronic advertising led display screen | Screen Dimension: | Customized Size |
Product Description
Full color P10 outdoor led display screen video hot free video play led screen for sale
1. Adopted die casting way to produce the cabinet‘s dimensional accuracy is very high. The split joint effect is perfect.
2. The weight of the cabinet is very light and installation way is very simple. The former two can satisfy the customer’s requirements of quick dismantle and installation.
3. New structure design to meet the fixed and hanging installation requirements.
4. Cost performance and convenient transportation
5. Long viewing distance and wide viewing angle.
P10 Outdoor Front Maintenance Full Color 320mm x 320mm Waterproof LED Module. The cabinet with this kind modules, its thickness can be designed thinner than traditional cabinets. It saves raw materials. During working if the modules malfunctioning, manitenance be comes more convenient. It saves time in maintaining. Because of the modules are easy to install and uninstall.
Application:
Supermarket, large scale shopping mall, exclusive agency, chain store, star rated hotel, restaurant, travel agency, pharmacy and etc outside wall mounted advertising use.
Pixel Pitch | 10mm |
Pixel Density | 10,000dots/sqm |
Color Configuration | 1R1G1B |
LED Encapsulation | DIP346 |
Module Size | 320mm x 320mm |
Module Resolution | 32dots x 32dots |
Drive Duty | 1/4 Constant Current |
Brightness | >7,500nits |
Viewing Distance | 10m - 100m |
Viewing Angle | H: 120°; V: 70° |
Refresh Rate | 2,000HZ |
Frame Rate | 120frame/sec |
Grey Grade | 256levels of Each Color |
Color Grade | 16.7M |
Power Input | 5V-20A, AC110V/ 220V/ 50HZ |
Max Power Consumption | 750W/sqm |
Ave. Power Consumption | 250W/sqm |
Storage Temperature | -40℃ ~ +80℃ |
Working Temperature | -20℃ ~ +60℃ |
Blind Spot Rate | <1/10000 |
MTBF | >10,000 Hours |
Life Span | >100,000 Hours |
Waterproof | IP65 |
Operating Humidity | 10%~95% |
Control System | Synchronous, Asynchronous |
Operating System | Win 98, Win2000, XP, 07.etc |
Input Source | All Format (AVI, MPEG,VOB, RM, etc) |
Certificate | CE, LVD, RoHS |
1. Pre-sales service:
a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
2. After-sales service:
a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.
Repair Service for LED Display Lifelong time
Usually, there are three tyeps of package design.
Firstly, we pack the LED display in the paper carton.
Secondly, we will pack the LED display in the flight case if customer request for frequent movement.
Thirdly, the favorable package method is wooden case package because of its lower cost and instant usage.
