DIP outdoor p16 led module

Specifications

1.DIP outdoor p16 led module
2.Big viewing angle
3.High brightness
4.2 years warra
5.CE,ROHS

DIP outdoor p16 led module

Feature and Advantage



1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system

2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system

3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof  your LED display screen's investment.

4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.

5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system

6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.



Our service



1.Your inquiry related to our products or price will be replied in 24hrs

2.OEM&ODM,any your customized lightings we can help you to design and put into product

3.Distributoership are offered for your unique design and some our current models

4.Protection of your sales area,ideas of design and all your private information

5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. Export countries :  Peru,  Mexico, Colombia, Turkey, US, UK, etc.



Trade Terms



1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery

2.Shipping freight are quoted under your requests

3.Shipping port: Shenzhen, Mainland China

4.MOQ:50pcs

5.Delivery time: 10days after receive pre-payment



p16 DIP football stadium perimeter LED screen display Parameter



Pixel Pitch:	16 mm
Pixel Density:	3906 pixels/sqm
Pixel Configuration:	1R1G1B
Module Dimension:	256*256 mm
Module Resolution:	16*16 pixels
Cabinets Dimension:	1024*1024 mm
Cabinets Resolution:	64*64 pixels
Brightness:	7500 cd/sqm
Best Viewing Distance:	> 16m
Average Consumption:	200 W/sqm
Max Consumption:	380 W/sqm
Viewing Angle:	Horizontal angle: 120 degree; Vertical angle: 60 degree
Processing:	12 bit
Ingress Protection:	Front IP67; Rear IP54
Refresh Rate:	300 to   4800Hz
LED lifetime:	100,000 hours
Input Voltage:	90 to 260VAC, 50/60Hz
Operation Humidity:	10% to 99%





 LED lamps material











High quality led connectors











LED Control system diagram



LED display certificates









Working factory:







p10 outdoor full color led display screen applications:
