Creative Diamond Shape LED Display P4mm Full Color Customized Video
1.High Stability, Power Saving
2. Convenient assemble and save space
3. High Cost Performance
4. Ultrathin
5. CE, 3C etc.
Perfect brightness. High quality, low cost .
Entertainment complexes, Churches, Restaurants, Showrooms, Casinos, Convenience Stores, Banking, Government facilities, Theatres and Retail outlets etc.
1. Pixel pitch: 4mm
2. Display color: Full color
3.Pixel Density: 62500 dots/m2
4.module Size: 128*128mm
5.resolution: 32*32 pixels
6.Scan: 1/16
7.Weight: 350G
Display type: Animation or Video, Full color picture or any Character
Use for: Indoor or semi-outdoor
1. First-class LED chip.Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness 2. High Contrast ratio: above 2000:1 .very high level to ensure a vivid image of our LED display screen system 3. Clear vivid image quality.more than 120 degree in horizontal and vertical to ensure you attract more audience to get short ROI of your LED display screen's investment 4. Long-term Brightness:use high quality led chip and lamp to ensure led display can last 11 years with low Lumens depreciation. 5.High definition. led display with high resolution to keep good video effect.
| Die-casting Aluminum P4 Led Display Screen | ||
| Pixel Information | Pixel Pitch | 4mm |
| Pixel Density | 62500 Pixels/m2 | |
| Pixel Configuration | 1R1G1B | |
| LED Wavelength | Red: 615 nm - 635 nm | |
| Green: 520 nm - 535 nm | ||
| Blue: 465 nm - 475 nm | ||
| LED Module | Module Size(mm) | 128 (Width) × 128 (Height) |
| Module Resolution | 32(Width) × 32 (Height) | |
| Cabinet | Cabinet Size(mm) | 512 (Width) ×512(Height) |
| Cabinet Resolution | 128 (Width) × 128 (Height) | |
| Total QYT Module Per Cabinet | 4 (Width) ×4(Height) | |
| Cabinet Weight | 30kg/m2 | |
| Cabinet Material | Die-casting Aluminum LED Display | |
| Power | Input Voltage | 100-240V AC, 50/60Hz |
| Max Power Consumption | 1200 Watt/m2 | |
| Avg. Power Consumption | 720 Watt/m2 | |
| Brightness | ≥1800cd/m2 | |
| Brightness Uniformity | Luminance Discrepancy < 5% | |
| Best Viewing Angle | Horizontal:140°,Vertical:70° | |
| Viewing Distance | 5 - 15 meters | |
| Ambint Conditions | Temperature Range | Working:-20deg. to +60deg |
| Operating Humidity | 10%90%RH | |
| Ingression Protection Grade | IP30 | |
| Processing | Scanning Mode | 1/16 scanning |
| Refresh Frequency | 600-1200HZ, Adjustable(depends on control system) | |
| Signal Input | DVI, Composite Video for Live Video | |
| Supported Networking | Through LAN/WAN, RS 232/RS485 | |
| Controller | Linsn or Nova | |
