Innovative products for import P2 full color video china led display
1. Name:JC-SIF-PH2mm
2. Brightness :2500cd/m2
3. Module Size:500*500*50.8mm
4. Grey Scale: RGB 16bit
5. Protection:Indoor
6. Cabinet Material:Carbon fiber
Indoor full color led display adopts SMD (Surface Mounted Device) or dot matrix technology. Indoor full color display is clearer than outdoor in terms of picture quality. The brightness of indoor panel is about 2000 nits. It has no need for indoor panel to use waterproof cabinets. Indoor panel includes wall mounted screen, single and tri-color screen. Full color indoor panel can be used to play video as advertising. Single and tri-color panel is usually used to show important information or notice, even weather forecast. Wall mounted indoor screen always adopts front maintenance method because it is impossible to open the cabinet from the back.
Indoor screen can usually be seen in all kinds of stations as message board, on the stage as background wall and in football or basketball field as score sign or side screen.
The best viewing distance of indoor panel is usually small in order to guarantee a clear look at the screen. So you can see the picture of indoor display clearly in a near distance. The size of indoor screen is not large because its viewing distance is nearer than outdoor screen.
1. Double power for back-up,double signal for insurance
2. LED info display on real time: indicating operating time
Product performance and product temprature
3. High definition high precision image performance
4. Black lights ,black mask ,entire blace 1010 LED ,PWM energy saving IC
5. Lamp drive of dividing radiating ,soft and hard combined plate ,FPC+PCB
Performance Advantages:
1. High resolution: The pixel is high, so that it can match LCD to some degree.
2. Super long service life: The luminance parts use the brand of American Cree as the core material of the electronic signs led display, thus fundamentally guaranteeing the service life of the product.
3. Wide visual angle: 160° wide visual angle and the high consistency of every LED make the audience gain the same first-class pictures from any angle within this range.
4. Stable performance: We have made unique treatment on the anti-electromagnetic wage of the led screen to ensure its stable performance.
5. Seamless splice: The splicing error between the led models is controlled within ±0.1mm, which is convenient for installation, and the electronic display signs can be made into any shape according to customer’s need.
Features
1.Easy to maintain, High resolution, Good contract, Less Weight, easy to install. Widely used as the information billboard in Airport, Railway station, and big shopping mall, concert and ect.
2.The brightness of indoor LED signs is adjustable so as to ensure different environment.
3.Indoor SMD LED signs include PH4mm, PH5mm, PH6mm, PH7.62mm, PH10mm and PH12mm. P6mm and P7.62mm are most popular pixel pitch.
4.We make best design with high cost- efficiency according to the actual needs of our customers and we can offer OEM service as well.
5.We produce advertising LED display, rental LED display, traffic LED display, highway LED display, stadium LED display, curve shape LED display, text information LED display and so on.
exhibition ,science& technology museum stage ,bar , entertainment and public place. The indoor full color P2 electronic led display boards have high reliability, saturated colors, high brightness, low power consumption, long service life and wide visual angle, so that they are widely used in theatre, sports field, TV studio, exhibition hall, conference center, security trading center, airport, superstore, bus station, business building, hotel and stage.
Pixel configuration |
SMD2020 1R1G1B 3 in 1 |
|
LEDs configuration |
Red:wave length: 625~630nm;300-400mcd |
|
Pixel pitch(mm) |
1.8mm |
|
Pixel density |
308025 |
|
Calibrated brightness(cd/sqm,nit) |
1500 nits(adjustable) |
|
Calibrated brightness proportion ratio |
R: G: B = 30%:60%:10% |
|
Color temperature |
3,500°--9,500° K(adjustable) |
|
Contrast ratio |
4,500:1 |
|
Brightness adjustment(dimming) |
100 grade auto/manual-adjustment |
|
View angle(degree)(50% brightness) |
Horizontal: 160° (80° off center); Vertical: 160° (80° off center) |
|
Readability viewing angle |
Horizontal/ Vertical: 170° (85° off center) |
|
Color capability |
4.4 trillion |
|
Refresh rate(Hz) |
>800 Hz |
|
Frame frequency(Hz) |
>60 Hz |
|
Interface port |
DVI interface(DVI connector) |
|
Input signal |
VGA, Video, AVI, MOV, MPG, DAT, VOB etc. |
|
Protection grade |
IP65 front side/IP54 backside |
|
LED Drive |
Constant-current drive |
|
Lifetime(hours)(50% brightness) |
100,000 hours |
|
Signal transmission direction |
Horizontal |
|
Operating temperature |
-30-65' |
|
Storage temperature(Celsius degree) |
-35-70' |
|
Operation humidity(RH) |
0-95% |
|
Operation humidity(RH) |
0-99% |
|
Servicing |
Front and back serving optional |
|
Control mode |
Synchronous & asynchronous available |
|
Communication options |
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS |
|
Power |
120/240 V AC single phase(50-60Hz) |
|
Maximum power |
1000 |
|
Average power consumption(W/SQM) |
400 |
|
Screen operation mode(scan/static) |
1/16 |
|
Module configuration |
Length |
64 |
Height |
32 |
|
Module dimensions(mm) |
Length |
179.2 |
Height |
89.6 |
|
Cabinet configuration |
Length |
3 |
Height |
6 |
|
Cabinet dimensions(mm) |
Length |
538 |
Height |
538 |
|
Width |
170 |
|
Screen configuration |
Length |
4 |
Height |
3 |
|
Screen dimensions(m) |
Length |
2.1504 |
Height |
1.6128 |
|
Screen Size |
SQM |
3.4682 |
Recommend Optimal Viewing Distance: Minimum & Maximum |
Min |
2 |
Max |
38 |
|
Resolution ratio(dots/pixels) |
Length |
768 |
Height |
576 |
|
Aspect Ratio(L:H) |
1.33333 |
|
Packaging configuration |
2 standard cabinets in a packing case(1 cabinet in 1 packing case when the unit cabinet is more than 1.5SQM) |
|
Packing material |
Wooden case/carton/flight case(optional) |
|
Packing quantities |
6 |
|
Packing volume(CBM) |
1 |
|
Packing Dimensions(mm) |
Length |
643 |
Height |
743 |
|
Width |
520 |
|
Packing weight(KG) |
net |
130 |
gross |
176 |
|
1. Pre-sales service:
a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
2. After-sales service:
a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.
Repair Service for LED Display Lifelong time
Usually, there are three tyeps of package design.
Firstly, we pack the LED display in the paper carton.
Secondly, we will pack the LED display in the flight case if customer request for frequent movement.
Thirdly, the favorable package method is wooden case package because of its lower cost and instant usage.
