Serve Cnc Water Jet Cutting Machine Price
US$ 26,000 - 48,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
TIANJUN
Model Number:
TJJ 300
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
420MPA KMT Super-high Pressure Water-jet Cutting EquipmentUS$ 47,000 - 47,900MOQ: 1 Unit -
300mpa KMT High Pressure Water Jet MachineUS$ 25,000 - 49,000MOQ: 1 Unit
-
TJJ TYPE High Pressure Water Jet Cutting MachineUS$ 25,000 - 50,000MOQ: 1 Set
-
TJY TYPE Super-high Pressure Water-jet Cutting MachineUS$ 35,000 - 56,000MOQ: 1 Set
-
TJY 420mpa Super High Pressure Water Jet MachineUS$ 35,000 - 55,000MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
TIANJUN
Model Number
TJJ 300
Condition
New
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Water jet cutting machine1.Adjusted arbitrary in rated range.
2.Simple in structure.
3.With smooth operation.
TJJ 300TYPE Super-high Pressure Water jet Cutting Equipment
With high pressure pump, original USA ACC INTENSIFIER. Cutting more accuracy and stable performance.
Machine technical datas
| System features | |||||||
| Cod. | Component | ||||||
| 1 | WORKINGTABLE WITH travel:3000*2000 (have seven size) | ||||||
| 2 | HITH PRESSURE INTENSIFIER PUMP 17.5KW | ||||||
| 3 | CNC NUMERICAL CONTROL INDEPENDENTLY DEVELOPED | ||||||
| 4 | PRESSURIZED ABRASIVE TANKING kg 20 WITH MINIHOPPER | ||||||
| 5 | I CUTTING HEAD IMPORT FROM ENGLAND | ||||||
| 6 | INDEPENTLY DEVELOPED SOFTWARE WITH AUTOMATIC NESTING | ||||||
DESCRIPTION OF THE EQUIPMENT
| WORKING TABLE AREA | OUTSIDE TABLE DIMENSIONS | ||||||
| X- AXIS | 3000 MM | X- AXIS | 3050MM | ||||
| Y- AXIS | 2000MM | Y- AXIS | 2050MM | ||||
| Z- AXIS | 150MM | Z- AXIS | 150MM | ||||
| WORKING TABLE HEIGHT | 1000MM | CUTTING ACCURANCY | 0.2MM | ||||
| Voltage/Frequency | 380V/50HZ | ||||||
| REPEATIBILITY | 0.01MM | RAPID TRAVERSE SPEED | 0~ 12M | ||||
| TABLE STRUCTURE | |||||||
| CANTIEVER STRUCTURE: convenient for loading material | |||||||
| SPECIAL DESIGN: two holes with the tank for cutting jet water out while jet water reach 1000mm | |||||||
| Catcher net fixed the water tank for the cutting pieces |
Water Jet Machine photos:
Water jet final products can be:
QUALITY CONTROL:
OUR CUSTOMERS COVER:
OUR COMPANY:
