High Output PVC Foam Board Machine/WPC Foam Board Extruder/PVC Free Foam Board Machine
The only professional Manufacturer of PVC WPC Foam Board Machine in China!!!
GENERAL SPECIFICATION
1 |
Brand Name |
SANYI |
2 |
Certificates |
CE, ISO9001, SGS, TUV |
3 |
Plastic Processed |
PVC and WPC |
4 |
Screw Design |
Conical double screw |
5 |
Model |
SJSZ80/173 |
6 |
Dimension (L*W*H) |
25m*3m*3m |
7 |
Capacity |
600kg/h |
8 |
Specification of Finished Board |
1220*2440*(3-30) mm |
9 |
Density of Finished Board |
0.37-0.85 adjustable |
10 |
Voltage |
380-440V |
11 |
Main Motor Power |
90kw |
12 |
Required Transformer Capacity |
250KVA |
13 |
After-sales Service |
Engineers available to serve overseas |
14 |
Application of Foam Board |
Furniture board, building template, decoration board, advertisement board, wall panels, roof, car and boat board etc. |
15 |
Packing Details |
Wood package and PE film covered 2 containers |
16 |
Delivery Dates |
30days after 30% down payment |
PRODUCT INTRODUCTION
Devoted to the R&D and Manufacture of PVC Foam Board Extrusion Machine for more than 8 years, SANYI has upgraded its PVC foam board machine to 13th generation. Well-equipped Extrusion Line and mature technology and formula system create high quality PVC Crust/Celuka/Skinning Foam Board.
TECHNIQUE GUARANTEE
Our PVC foam board machine adopts Celuka foam technology, which can produce a kind of PVC foam boards with superior quality. These processes result in a "skinning" or outer layer of foam board and harder or more scratch resistant. This kind of PVC foam board can not only have much smoother surface but also have more skin hardness compared with other PVC boards.
EQUIPMENT STRUCTURES
|
Component |
Specification |
1 |
The 13th Generation Extruder |
90 kw (speed adjusted by SIMENS inverter) 80/173 conical double screw OMRON Temperature controller Output is about 600kg/h. Automatic feeder |
2 |
The 13th Generation Mould |
(3mm-20mm) x1220mmx2400mm |
3 |
Calibration Unit |
Calibration plate: 1500mm× 500mm 4couples |
4 |
Cooling roller system |
Length: 6000mm Trimming knife: 3 sets |
5 |
Haul off machine |
8 pairs rubber rollers (controlled by inverter) and electric trimming machine |
6 |
End Cutter |
controlled by inverter |
7 |
Stacker |
|
TOP ELECTRICAL CONFIGURATION
1. Main motor frequency controller: SIMENS or ABB
2. Temperature controller: OMRON or RKC
3. AC controller: SCHNEIDER or SIMENS
4. Thermal overload relay: SCHNEIDER
5. Switch: SCHNEIDER
PRODUCTION PROCESSING
Material Mixing: PVC + additives or PVC + wood powder + additives
Extrusion Processing: mixed material going through the extruder, Mould, calibration unit, cooling carrying roller and trimming cutter, and delivery device.
Final Products: PVC or WPC foam board
CHARACTERISTICS OF PVC WPC FOAM BOARD
PVC WPC foam board has such characteristics as sound separation, sound absorption, heat separation.
The material is incombustible, it is safe for use.
All series of products have property of moisture proof, mildew proof, water resistance; its vibration resistant effect is good.
All series of products have property of weathering proof, its luster may remain forever, and it is not easy to be ageing.
This product is light, storage & transport, construction are rather convenient.
This product can be worked with normal tools for wooden material.
Drilling, sawing, nail, bonding can be conducted like wooden material.
It is suitable for thermal shaping, thermal bending and fold processing.
It can be welded; it can also be bonded with other pvc material.
The surface of this product is smooth, it can be printed. (Clean the surface before printing).
SPECIFICATION OF FINISHED BOARD
Specifications of PVC Foam Board | |
Length |
1830mm/2440mm |
Thickness |
3mm~20mm |
Width |
915mm/1220mm |
Density |
0.37g/cm 3 -0.85g/cm 3 |
surface |
Smooth or wood grain pattern(timber ridge) finish |
color |
White, wood or all feasible colors as requested |
Application of PVC WPC Foam Board
1. Architecture decoration industry:
Building formwork board, outdoor board, indoor decoration board, residential house board, office board, separation wall of public building, commercial decoration frame, board used in dust-free room, etc.
2. Household decoration:
Bathroom cabinet board, kitchen cabinet board, furniture board, home decoration board, various household shelves, etc.
3. Advertisement industry:
Screen printing, computer engraving, advertisement board, exhibition plate, logo plate, etc.
4. Transportation industry:
Ship, plane, bus, and train, floor covering, core layer, indoors decoration plate, etc.
5. Industrial application:
Suitable for rot-proof project in chemical industry, thermal forming, refrigeration warehouse, etc.
6. Other applications:
Construction formwork, sports apparatus, aquaculture material, seashore wet-proof facility, water-resistant material, arts material and all sorts of light separation plate, etc.
Packing Details: Wood package and PE film covered 2 containers.
Delivery Details: 30 working days
1. Pre-sale service:
To provide market research information and consultation
To provide all kinds of convenience and market service.
To help customers make project planning and systematic analysis
To maximize customer's satisfaction
To achieve the mutual benefits of our customers and our company
2. After-sale service:
To install products and test products for customers
To provide the formulas and technologies of relevant products and the information of chemical materials manufactories
To provide technical direction according to customers' requirements
To provide technical training for clients' employees
To be responsible for maintenance service, door-to-door service under necessary circumstance.
Qingdao Sanyi Plastic Machinery Co., Ltd locates in Qingdao City. Our company has advanced technology and experiences in plastic machinery fields from 2006.We can transform the newest science research into real product with fastest speedy to supply the most competitive equipment for our customers. We can provide you our best after-sales service and abide by the principle of "Quality first, Credit uppermost". Qingdao sanyi plastic machinery co.,ltd is a professional manufacturer of PVC foam board extrusion line with good quality and competitive price. Also, we have CE and ISO9001:2008 and TUV certificates. We have enjoyed a good reputation in both China and the world. Our company has advanced to the latest generation and greatly improved the performance and output of the machine. The development of PVC foam board extrusion line witness our company's growth and strength.
Now we share 30% of the domestic market and also exported our products to the world such as America, India, Mongolia, Turkey, Kuwait, Romania, Dubai etc.
