Reusable PVC Construction Formwork Extrusion Line, PVC Foam Board Machine, WPC Foam Board Production Line
Brand Name: SanYi
Certificate: CE, ISO9001, SGS, TUV
Plastic Processed: PVC and WPC
Screw Design: Conical double screw
Model Number: SJSZ80/156
Voltage: 380-440V
Main Motor Power: 120kw
Dimension (L*W*H): 25m*3m*3m
Weight: 28t
Output of plastic plate: 400kg/h
Finished Product: PVC/WPC foam board
Specification of finished board: 1220*2440*(3-20) mm or 915*1830*(3-20)mm
Density of finished board: 0.37-0.85 adjustable
Application of Foam Board: Furniture board, building template, decoration board, advertisement board, wall panels, roof, car and boat board etc.
After-sales Service Provided: Engineers available to serve overseas
Packing Details: Wood package and PE film covered 2 containers.
Delivery Details: 30 working days
PRODUCT INTRODUCTION
PVC WPC Foam Board Machine is a production line Qingdao Sanyi have been devoted to and concentrated on during the last 8 years! It's continuously improved and redesigned on the basis of requirements and feedbacks from our customers combined with foreign advanced technology. It shows superior performance, high reliability and practicality with its compact structure, advanced configuration and outstanding output in the production of 3-30mm thick, high-qualified PVC WPC foam board, reusable PVC construction formwork.
TECHNIQUE GUARANTEE
Our PVC WPC foam board extrusion line adopts Celuka foam technology, which can produce a kind of PVC WPC foam boards with superior quality. These processes result in a "skinning" or outer layer of foam board and harder or more scratch resistant. This kind of PVC WPC foam board can not only have much smoother surface but also have more skin hardness compared with other PVC WPC boards.
EQUIPMENT STRUCTURES
|
Component |
Specification |
1 |
The 11th Generation Extruder |
75kw (speed adjusted by SIMENS inverter) 80/156 conical double screw OMRON Temperature controller Output is about 400kg/h. Automatic feeder |
2 |
The 11th Generation Mould |
(3mm-20mm) x1220mmx2400mm |
3 |
Calibration Unit |
Calibration plate: 1500mm× 500mm 4couples |
4 |
Cooling roller system |
Length: 6000mm Trimming knife: 3 sets |
5 |
Haul off machine |
8 pairs rubber rollers (controlled by inverter) and electric trimming machine |
6 |
End Cutter |
controlled by inverter |
7 |
Stacker |
|
TOP ELECTRICAL CONFIGURATION
1. Main motor frequency controller: SIEMENS or ABB
2. Temperature controller: OMRON
3. AC controller: SCHNEIDER or SIEMENS
4. Thermal overload relay: SCHNEIDER
5. Switch: SCHNEIDER
As one of the few STRATEGIC PARTNERs with SIEMENS in China, we apply the best electric equipment to our PVC WPC foam board machine, not only the production line but also the auxiliary equipments, to achieve stable, safe, and high-quality production of the board production!!!
PRODUCTION PROCESSING
Material Mixing: PVC + additives or PVC + wood powder + additives
Extrusion Processing: mixed material going through the extruder, Mould, calibration unit, cooling carrying roller and trimming cutter, and delivery device.
Final Products: PVC or WPC foam board
SPECIFICATION OF FINISHED BOARD
Specifications of PVC WPC Foam Board | |
Length |
1830mm/2440mm |
Thickness |
3mm~20mm |
Width |
915mm/1220mm |
Density |
0.37g/cm 3 -0.85g/cm 3 |
surface |
Smooth or wood grain pattern(timber ridge) finish |
color |
White, wood or all feasible colors as requested |
CHARACTERISTICS OF PVC WPC FOAM BOARD
WPCfoam board has such characteristics as sound separation, sound absorption, heat separation, temperature-keeping, etc.
The material is incombustible, it is safe for use.
All series of products have property of moisture proof, mildew proof, water resistance; its vibration resistant effect is good.
All series of products have property of weathering proof, its luster may remain forever, and it is not easy to be ageing.
This product is light, storage & transport, construction are rather convenient.
This product can be worked with normal tools for wooden material.
Drilling, sawing, nail, bonding can be conducted like wooden material.
It is suitable for thermal shaping, thermal bending and fold processing.
It can be welded; it can also be bonded with other pvc material.
The surface of this product is smooth, it can be printed. (Clean the surface before printing).
Packing Details: Wood package and PE film covered 2 containers.
Delivery Details: 30 working days
1. Pre-sale service:
To provide market research information and consultation
To provide all kinds of convenience and market service.
To help customers make project planning and systematic analysis
To maximize customer's satisfaction
To achieve the mutual benefits of our customers and our company
2. After-sale service:
To install products and test products for customers
To provide the formulas and technologies of relevant products and the information of chemical materials manufactories
To provide technical direction according to customers' requirements
To provide technical training for clients' employees
To be responsible for maintenance service, door-to-door service under necessary circumstance.
We specialize in manufacturing of PVC (WPC) Crust/Skinning Foam Board Extrusion Line in China. We have been keeping researching and developing our production line for more than 8 years and have improved to the latest 13th generation. Our PVC/WPC foam board extrusion line shows superior performance and capacity. It can be used to produce pvc/wpc construction formwork board, pvc/wpc furniture board, pvc/wpc advertisement board, pvc kitchen/bathroom cabinet board and so on.
Now we share 30% of the domestic market and also exported our products to the world such as America, India, Mongolia, Turkey, Kuwait, Romania, Dubai etc.
