Home > Instruments & Meters > Test Instrument > Test Machine > ISTA Standard Shock Absorber Testing Machine

ISTA Standard Shock Absorber Testing Machine

Name: ISTA Standard Shock Absorber Testing Machine
Brand: LABTONE
SKU: 119625481
Availability: InStock

ISTA Standard Shock Absorber Testing Machine thumbnail-1

ISTA Standard Shock Absorber Testing Machine thumbnail-2

ISTA Standard Shock Absorber Testing Machine photo-1

ISTA Standard Shock Absorber Testing Machine photo-2

US$ 1,000 - 20,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

LABTONE

Model Number:

SKT30

Contact Supplier Request Quote Chat Now

Shenzhen Labtone Test Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name LABTONE

Model Number SKT30

Power Electronic

Usage Impact Testing Machine

Product description

ISTA standard Shock Absorber Testing Machinee

Shock testing systems Design standards: GB/T2423-2008, GJB1217, GJB360.23, GJB150, GJB548, MIL-STD-202F, IEC-68-2-27, MIL-STD-883E, MIL-STD-810F, ISTA, UL

Shock testing systems Applications: aviation,aerospace,vessel,military industry,consumer electronics ,automobile,household appliances, display device etc.

Shock testing systems Features

User-friendly touching screen operation.Half sine, square waveform shock pulse programmers.High rigidity shock tables.
Half sine, square waveform shock pulse programmers.
High rigidity shock tables.
A full range of safety features.
Apply air and hydraulic pressurization, strong friction brake avoiding secondary shock.
Apply air spring suspension, hydraulic damping shockproof system, no shock impact on the surrounding, without foundation.

Shock testing System Block Diagram

Shock testing systems Specifications

Model		SKT30	SKT50	SKT100	SKT200	SKT300	SKT600	SKT1000
Table size (cm)		40*40	50*60	70*80	100*100	120*120	150*150	200*200
Maximum Specimen Weight(Kg)		30	50	100	200	300	600	1000
Maximum Specimen Weight(Kg)		30	50	100	200	300	600	1000	Max. Acceleration (G)	half sine	600	600	600	500	500	300	300
saw-tooth waveform	100	100	100	100	100	100	100
square		150	150	150	100	100	100
Pulse Duration (ms)	half sine	40—0.2	40~1	40~1	30~2	20~3	20~3	20~3
	saw-tooth waveform	18~6	18~6	18~6	18~6	18~6	18~6	18~6
	square		30~6	30~6	30~6	30~6	30~6	30~6
Machine Dimension(cm)		120110245	130140260	130120260	150130260	200160300	230180310	250220310
Controller cabinet Dimension(cm)		W55D50H80
Machine Weight(Kg)		1900	2300	3200	4200	8500	15500	19500
Utility Requirements		3-phase AC380V 50/60Hz 0.5~0.8MPa
Conforming standards		GB/T2423-2008 GJB1217 GJB360.23 GJB150 GJB548 MIL-STD-202F IEC-68-2-27 MIL-STD-883E MIL-STD-810F ISTA UL

High acceleration shock testing systems applications: mobile phone, computer components, connector, optical component, mobile product etc.

High acceleration shock testing systems specifications:

Model	HSKT10	HSKT10	GSKT10D
Table size (cm)	15*15	20*20	20*20
Shock pulse	Half sine
Maximum Specimen Weight(Kg)	5	10	10
Acceleration Range(G)	20 ~ 1500	20 ~ 1500	20 ~ 10000
Pulse Duration (ms)	0.5~11	0.5~11	0.2~11
Machine Dimension(cm)	6055250	6055250	9070275
Utility Requirements	AC220V 50Hz 5A,Air pressure: more than 0.5Mpa
Machine Weight(Kg)	600	650	110
