Drop test machine for package
High Accuracy Drop Tester for Packaged Freight Description & Application
Packaging drop tester is used to measure the dropping impact incidence when the package in using, transportation and decorating. Labtone "1G+" project strictly ensure the accuracy. Besides precision plane drop testing, it also can undertake edge and angle test to ensure the complete performance evaluation for the package.
High Accuracy Drop Tester for Packaged Freight Features
1,Unique swing arm mechanism design, swing arm break away from acceleration more than 3 G/SEC.
2,With double column guide and hydraulic buffer absorb residual swing arm force, movements smooth, reliable, low noise.
3,Damping screw lifting mechanism, preventing drop institution unexpectedly glide.
4,Pneumatic automatic chain, preventing swing arm unusual break away.
5,Extensible support bracket and baseboard.
High Accuracy Drop Tester for Packaged Freight specifications
| Model | DT150 | DT200 |
| Drop height range(mm) | 300---1500 | 300----2000 |
| Specimen max.weight(kg) | 85 | 85 |
| Specimen max. size(mm) | 800*800*800 | 800*800*800 |
| Drop mode | Freedom | |
| Machine Dimension(mm) | 1500*1000*2150 | 1700*1200*2750 |
| Machine weight(kg_ | 480 | 550 |
| Power supply | AC220V 50Hz compressed air 0.5~0.7Mpa | |
| Standards | ISO2248-72(E) GB/T4857.5 JISZ0202-87 IEC68-2-27 | |
Internatinal Standard Wood Case
| Pre-sales service |
| Technical Advisory: Testing method, laboratory planning and advice |
| Equipment Selection: Type-selecting scheme,FAQ |
| Product testing scheme |
| Selling service |
| Customer Communication,progress communication |
| Before installation, we will provide guidance of preparation , equipment debugging, equipment commissioning |
| Cooperate with measuring if need the third party verification |
| After-sale service |
| Quality assurance period for one year,lifelong maintenance. |
| Technical guidance |
| Feedback within 2 hours after get the call. |
| Accept OEM,Design service,Buyer lable |
Shenzhen Labtone Test Equipment Co., Ltd. was established in 2002 and specialized in simulation testing equipment under mechanical environment, integrating development and production together. This includes Vibration testing systems, Shocking testing systems, Drop tester, Bump testing machines, Vibration-temperature humidity combined reliability testing systems, etc. Our products are used in a variety of applications, such as automotive,electronics,aerospace,vessel,telecommunication,optoelectronics ,instrument etc. Currently, our products are exported to Southeast Asia, Occident and other countries and regions. And they are widely recognized and trusted by users. Besides, we are making great efforts to develop new products to meet different requirements. Adhering to the business principle of mutual benefits, we have built up a good reputation among our customers due to our perfect services, quality products and competitive prices. We warmly welcome customers from domestic and overseas to cooperate with us for common success.
