K01-65mm Mini 3 Jaw Chuck For Lathe Chuck Mini Collet

FOB Price

US$ 25 - 1,100 / Piece

1 Piece(Min. Order)

Port DALIAN
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Liaoning, China	Brand Name	HR
Model Number	3 jaw chuck	Power	Manual
Number of Jaws	3

Product Description

K01-65mm Mini 3 Jaw Chuck For Lathe Chuck Mini Collet

Three-jaw Self-centering chuck is subdivided into three types,K11,K11A,K11C.
Type K11A provides,ISO3442 standard clutches,and Type K11C provides traditional separate clutches.
Soft clutches are to be provided on request,higher centring accuracy can be achieved after being rubbed on the machine,so as to satisfy the need for holding.

Specification:

Product name	K01-65mm Mini 3 Jaw Chuck For Lathe Chuck Mini Collet
casting material	Ductile iron, Tool steelor as your demand
Tolerance of Chucks	+/-0.01mm
Lathe parts	3 jaw chuck
Structure of Chucks	vertical type woth baseboard
Max Speed	2500
lamping range of inner diam	D3-90
clamping range of outer dia	D32-84
processing	Lathe chuck
Total clamping force	31 kN
Packaging	Chuck each plastic bag to a carton. Or up to you

Factory Production

Model Size D	D1	D2	D3	H	H1	H2	h	Z-d
K1180	55	66	16	66	50	-	3.5	3-M6
K11100	72	84	22	74.5	55	-	3.5	3-M8
K11125	95	108	30	84	58	-	4	3-M8
K11130	100	115	30	86	60	-	3.5	3-M8
K11160	130	142	40	95	65	-	5	3-M8
K11160A		142	40	109	65	71	5	3-M8
K11165		145	40	96.5	66.5	-	4.5	3-M8
K11165A		142	40	96.5	66.5	-	4.5	3-M8
K11190	155	172	55	109	75	-	5	3-M10
K11200	165	180	65	109	75	-	5	3-M10
K11200A		180	65	122	75	80	5	3-M10
K11200C		180	65	122	75	78	5	3-M10
K11240	195	215	70	120	80	-	8	3-M12
K11240A		215	70	136	80	86	8	3-M12
K11240C		215	70	130	80	84	8	3-M12
K11250	206	226	80	120	80	-	5	3-M12
K11250A	206	226	80	136	80	86	5	3-M12
K11250C	206	226	80	130	80	84	5	3-M12

Process

Our process

Packaging & Shipping

Our Packing and Shipping

Transport

Our transport

Our Services

We value every inquiry sent to us, ensure quick competitive offer within 12 hours.

We cooperate with customer to design and develop the new products. Provide all necessary document.
We are a sales team, with all technical support from engineer team.

Why choose us?

Advantages we have:

1. Experienced slate products supplier"

2. Professional design team and sales department for your service;

3. 9year alibaba gold supplier, factory recognized by 'CE/ISO9001' and so on;

4. 7*24 service for you, all the question will be dealed within 24hours.

Benefit you get:

1. Stable quality  ——  Coming from good materials and technic

2. Lower price     ——  Not cheapest but the lowest at the same quality

3. Good service  ——  Satisfactory service before and after sale

4. Delivery time   ——  30-45 days for mass production
