Home > Products > plastic board machine > Substitute for MDF Board Production Line---PVC Celuka Board Machine
Substitute for MDF Board Production Line---PVC Celuka Board Machine
- 10 Set / Sets per Month
- Qingdao
- T/T
Product Details
Condition: | New | Application: | Plates | Plastic Processed: | PVC |
Screw Design: | Double-screw | Automatic Grade: | automatic | Place of Origin: | Shandong, China |
Brand Name: | SANYI | Model Number: | SJSZ80/156 | Voltage: | 380-440V |
Power(W): | 75kw | Dimension(L*W*H): | 25m*3m*3m | Weight: | 28t |
Certification: | CE, ISO9001, SGS, TUV | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Substitute for MDF Board Production Line---PVC Celuka Board Machine
Brand Name: SanYi
Established Time: 2006
Certificate: CE, ISO9001, SGS, TUV
Plastic Processed: PVC and WPC
Screw Design: Conical double screw
Model Number: SJSZ80/156
Voltage: 380-440V
Main Motor Power: 75kw
Dimension (L*W*H): 25m*3m*3m
Weight: 28t
Output of plastic plate: 400kg/h
Finished Product: PVC/WPC foam board
Specification of finished board: 1220*2440*(3-30) mm or 915*1830*(3-30)mm
Density of finished board: 0.37-0.85 adjustable
Application of Foam Board: Furniture board, concrete formwork, decoration board, advertisement board, wall panels, roof, car and boat board etc.
After-sales Service Provided: Engineers available to serve overseas
Packing Details: Wood package and PE film covered 2 containers.
Delivery Details: 30 working days
PRODUCT INTRODUCTION
CHARACTERISTICS OF PVC WPC FOAM BOARD
PVC foam board has such characteristics as sound separation, sound absorption, heat separation.
The material is incombustible, it is safe for use.
All series of products have property of moisture proof, mildew proof, water resistance; its vibration resistant effect is good.
All series of products have property of weathering proof, its luster may remain forever, and it is not easy to be ageing.
This product is light, storage & transport, construction are rather convenient.
This product can be worked with normal tools for wooden material.
Drilling, sawing, nail, bonding can be conducted like wooden material.
It is suitable for thermal shaping, thermal bending and fold processing.
It can be welded; it can also be bonded with other pvc material.
The surface of this product is smooth, it can be printed. (Clean the surface before printing).
EQUIPMENT STRUCTURES
| Component | Specification |
1 | The 11th Generation Extruder | 75kw (speed adjusted by SIEMENS inverter) 80/156 conical double screw OMRON Temperature controller Output is about 400kg/h. Automatic feeder |
2 | The 11th Generation Mould | (3mm-30mm) x1220mmx2400mm |
3 | Calibration Unit | Calibration plate: 1500mm× 500mm 4couples |
4 | Cooling roller system | Length: 6000mm Trimming knife: 3 sets |
5 | Haul off machine | 8 pairs rubber rollers (controlled by inverter) and electric trimming machine |
6 | End Cutter | controlled by inverter |
7 | Stacker |
|
TOP ELECTRICAL CONFIGURATION
1. Main motor frequency controller: SIMENS or ABB
2. Temperature controller: OMRON or RKC
3. AC controller: SCHNEIDER or SIMENS
4. Thermal overload relay: SCHNEIDER
5. Switch: SCHNEIDER
As a Strategic Partner with Germany Siemens, Sanyi promise all the siemens electric devices adopted are authentic Germany siemens.
PRODUCTION PROCESSING
Material Mixing: PVC + additives or PVC + wood powder + additives
Extrusion Processing: mixed material going through the extruder, Mould, calibration unit, cooling carrying roller and trimming cutter, and delivery device.
Final Products: PVC or WPC foam board
SPECIFICATION OF FINISHED BOARD
Specifications of PVC WPC Foam Board | |
Length | 1830mm/2440mm |
Thickness | 3mm~30mm |
Width | 915mm/1220mm |
Density | 0.37g/cm 3 -0.85g/cm 3 |
surface | Smooth or wood grain pattern(timber ridge) finish |
color | White, wood or all feasible colors as requested |
APPLICATION OF PVC WPC FOAM BOARD MACHINE
1. Building industry:
Building formwork board, outdoor board, indoor decoration board, residential house board, office board, separation wall of public building, commercial decoration frame, board used in dust-free room, etc.
2. Household decoration:
Bathroom cabinet board, kitchen cabinet board, furniture board, home decoration board, various household shelves, etc.
3. Advertisement industry:
Screen printing, computer engraving, advertisement board, exhibition plate, logo plate, etc.
4. Transportation industry:
Ship, plane, bus, and train, floor covering, core layer, indoors decoration plate, etc.
5. Industrial application:
Suitable for rot-proof project in chemical industry, thermal forming, refrigeration warehouse, etc.
6. Other applications:
Construction formwork, sports apparatus, aquaculture material, seashore wet-proof facility.
Packing Details: Wood package and PE film covered 2 containers.
Delivery Details: 30 working days
1. Pre-sale service:
To provide market research information and consultation
To provide all kinds of convenience and market service.
To help customers make project planning and systematic analysis
To maximize customer's satisfaction
To achieve the mutual benefits of our customers and our company
2. After-sale service:
To install products and test products for customers
To provide the formulas and technologies of relevant products and the information of chemical materials manufactories
To provide technical direction according to customers' requirements
To provide technical training for clients' employees
To be responsible for maintenance service, door-to-door service under necessary circumstance.
We specialize in manufacturing of PVC (WPC) Crust/Skinning Foam Board Extrusion Line in China. We have been keeping researching and developing our production line for more than 8 years and have improved to the latest 13th generation. Our PVC/WPC foam board extrusion line shows superior performance and capacity. It can be used to produce pvc/wpc construction formwork board, pvc/wpc furniture board, pvc/wpc advertisement board, pvc kitchen/bathroom cabinet board and so on.
Now we share 30% of the domestic market and also exported our products to the world such as America, India, Mongolia, Turkey, Kuwait, Romania, Dubai etc.
