High Quality Solar Panel For Air Conditioner With 6v Small Solar Panel

High Quality Solar Panel For Air Conditioner With 6v Small Solar Panel thumbnail-1
High Quality Solar Panel For Air Conditioner With 6v Small Solar Panel photo-1
US$ 0.48 - 0.55 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
OEM
Material:
Monocrystalline Silicon
Contact Supplier Request Quote Chat Now
Unifit Industrial Supply Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NANJING/NANTONG/ZHANGJIAGANG/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name OEM
Material Monocrystalline Silicon
Size 1230*668*35MM
Number of Cells 36pcs
Max. Power 120w

High Quality Solar Panel For Air Conditioner With 6v Small Solar Panel  High Quality Solar Panel For Air Conditioner With 6v Small Solar Panel

1.Performace test data for each module

2.Power output warranty:10 years:90%,25 years:85%

3.Bypass diodes to reduce loss in partial shadow



Quality and Safety



1.Rigorous quality control meeting the highest international standards



2.High-transmissivity low-iron tempered glass, strong aluminium frame



3.Using UV-resistant silicon



4.ISO 9001:2008 and ISO 14001:2004



5.IEC61215, IEC61730, Safety Class in conformity to CE



Features



 1.High conversion efficiencies resulting in superior power output performance.

 2.Outstanding power output even in low light or high temperature conditions

 3.Optimized design for ease of soldering and lamination

 4.Long-term stability,reliability and performance



Temperature Coefficient



temperature coefficients Maximum System Voltage        1000VDC
Voc      -0.389 %/℃
Isc      +0.057 %/℃
Pm -0.47%℃



Model No. Power Rating (Wp) Dimension(mm)  Vm(v) Im(A) Voc(V)  Isc(A)  Cells Eff  Module Eff
ODA120-18-M 120W 1230*668*35 18.82 6.59 22.61  7.05  17.25%  14.60%
ODA115-18-M 115W 1230*668*35 18.82 6.13 22.58  6.74  16.53%  14.00%
ODA110-18-M 110W 1120*668*35 18.51 5.96 22.61  6.36  16.90%  14.70%
ODA105-18-M 105W 1120*668*35 18.82 5.60 22.58  6.16  16.10%  14.03%
ODA100-18-M 100W 1008*668*35 18.78 5.34 22.64  5.70  17.25%  14.85%
ODA95-18-M 95W 1008*668*35 18.20 5.24 21.84  5.74  16.98%  14.11%
ODA90-18-M 90W 1008*668*35 18.69 4.84 22.43  5.32  16.09%  13.37%
ODA85-18-M 85W 905*668*35 18.25 4.68 21.90  5.15  16.98%  14.06%
ODA80-18-M 80W 905*668*35 18.69 4.30  22.43  4.73  16.02%  13.23%
ODA75-18-M   75W 770*668*30 18.57 4.04 22.64  4.32  17.96%  14.58%
ODA70-18-M   70W 770*668*30 18.82 3.74 22.58  4.11  16.76%  13.61%
ODA65-18-M 65W 720*668*30 18.87 3.46 22.68  3.69  16.98%  13.51%
ODA60-18-M   60W 655*668*30 17.95 3.36 22.57  3.58  17.04%  13.71%
ODA55-18-M 55W 655*688*30 18.08 3.07 22.59  3.25  16.02%  12.57%
ODA50-18-M 50W 590*668*30 18.57 2.72 22.64  2.88  17.96%  12.69%
ODA45-18-M 45W 590*668*30 18.01 2.53 21.61  2.78  15.63%  11.42%
ODA40-18-M 40W 500*668*25 18.69 2.16 22.43  2.38  16.56%  11.98%
ODA35-18-M 35W 440*668*25 18.82 1.90 22.58  2.09  16.76%  11.91%
ODA30-18-M 30W 710*360*25 18.57 1.62 22.64  1.73  16.96%  11.71%
ODA25-18-M 25W 570*360*25 18.57 1.35 22.64  1.44  17.25%  12.18%
ODA20-18-M 20W 485*360*20 18.82 1.08 22.58  1.19  17.25%  11.45%




Module Dimension & Diagram





IV Carve





High Quality Solar Panel For Air Conditioner With 6v Small Solar Panel



Product Description





Earnest Production

 High Quality Solar Panel For Air Conditioner With 6v Small Solar Panel



soler cell information



Payment Terms

T/T, L/C, Western Union, Paypal and Escrow are the payment methods we accept at present.



Shipping

Materials in stock can be produced (procedure 5-20days) right away after pre-payment confirmation. COSCO, Mearsk and MSC ship to worldwide for safe shipping, so don't worry about package damage or loss. It takes about 15-40 days to worldwide, Please note us your contact details, including your phone number, for easy contacting from shipping company officer.



Important Information

1. All our solar panels following IEC6125, IEC61730 standard, Have CE, TUV Certifications.

2. The solar cell efficiency is 16%-18.5%. All material certificates by TUV IEC test, meet the solar panel 25 years at outdoor performance.



Feedback

1. Customer satisfaction is completely guaranteed. If for any reason you are unsatisfied with your order, please contact us first before you leave the feedback.

2. We will do our best to take care of you. If you have any questions, please do not hesitate and feel free to contact us.
