TJ-60 GRANITE MABLE CNC STONE CUTTING MACHINE
US$ 34,000 - 36,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other, Tile Cutting Machine, Different sizes offered
Tile Type:
Concrete
Use:
Floor
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TJCZ Portal Two-Way Stone CutterNegotiableMOQ: 1 Set -
Stone Machines and Tools, Served to Turnkey PlantUS$ 16,000 - 20,000MOQ: 1 Set
-
LCQJ-22/28/30 Manual Tile Stone Cutting MachineUS$ 5,500 - 6,500MOQ: 1 Set
-
TJZJ Stone Segment Cutting MachineNegotiableMOQ: 1 Set
-
Infrared Fully Automatic Bridge Type Edge Cutting Machine,cutting EdgeUS$ 24,000 - 26,000MOQ: 1 Set
Type
Other, Tile Cutting Machine, Different sizes offered
Tile Type
Concrete
Use
Floor
Place of Origin
Shandong, China
Brand Name
TIAN JUN
Model Number
TJ-60
Specifications
TJ-60 CNC PROCESSING MACHINEcompetitive price
good quality
TJ-60 CNC processing machine is one multifunctional, advanced stone procession machine. It is used for cutting and profiling marble,granite, artificial stone and so on.
| model | TJ-60 | ||||||
| max cross stroke | 3300mm | ||||||
| max longitudinal stroke | 3200mm | ||||||
| Max up-down stroke | 500mm | ||||||
| blade max cross moving speed | 16500mm/min | ||||||
| blade max longitudinal moving speed | 18000mm/min | ||||||
| table max tilting degree | 85° | ||||||
| table rotating degree | A) 0°,45°,90°,180°,270° (fixed) | ||||||
| B) 360° continuous rotation | |||||||
| C) 0~180°swinging | |||||||
| Table size | 3250×2000mm | ||||||
| guide rail of side beam and main crossbeam | Straight guide rail | ||||||
| Total power | 16.1KW | ||||||
| Main motor | 11KW/4—frequency adjustable | ||||||
| carriage walking motor (servomotor) | 1.2 KW | ||||||
| crossbeam moving motor (servomotor) | 1.2 KW | ||||||
| up down motor (servomotor) | 1.2KW | ||||||
| oil pump motor | 1.5 KW | ||||||
| standard working pressure | 5.5Mpa | ||||||
| machine size | 5800×4500×3300mm | ||||||
| Total weight | 5500 kg | ||||||
