Help CenterMixing Truck for Drilling Operations
Related Products
Specifications
1.API standard2.Advanced high energy mixing technology
3.High efficiency and water-saving
4.Anti-collision
BACT-300-100A continuous batch mixing truck
Product Explanation:According to actual work situation, BACT-300-100A continuous batch mixing truck is designed for high quality slurry new equipment which can continue and batch mixing. The unit is used in North Benz 6 X4 chassis; install two hydraulic auxiliary struts, which can meet the demand of flexibility and bearing demand of batch mixing installation The truck is supplied motivation by engine, output motivation to three sets of centrifugal pump and blender motor respectively through gear box hydraulic system, which is mainly used in high demand of slurry’s density cement work.
Product Features
1.Auxiliary hydraulic under propping, to meet bearing demand
2.Continuous mixing as well as batch mixing ,manually operation as well as automatic operation
3.Advanced high energy mixing technology. Slurry goes into batch mixing tank though HEMI system, and then average to ensure the stability of slurry’s quality.
4.Adopt the international popular configuration 2x50BBL, and install large power blender in each tank
5.High efficiency and water-saving of semi-automatic batch tank water system
General performance | |
Dimension |
10250 x 2500 x 4150 mm ( length x width x height ) |
Weight |
About 22 t |
Engine power |
300HP/2200 RPM |
Continue Mixing Capacity |
0.3-2.3m³/min |
Density Range |
1.3-2.5g/cm³ |
Density Precision |
+/-0.02 g/cm³ |
Batch Mixing Tank volume |
2x50BBL |
Mixing Tank Volume |
1.2m³ |
Working Temperature |
-20°C~+50°C |
Configuration | |
Chassis |
North Benz 6X4 or 6X6 |
Engine |
caterpillar C7 300HP@2200RPM |
Gear Box |
Funk 59000 series |
Hydraulic system |
Eaton heavy close hydraulic system |
recirculating centrifugal pump |
Serva RA56 |
Pressure centrifugal pump |
Serva RA56 |
Water centrifugal pump |
Serva 4X3X11 |
Mixing system |
high energy mixing system |
control system |
ACM-III.1 fluid level auto control system |
mixing tank volume |
1.2 m³ |
batch mixing volume |
2X50BBL |
