Specifications
1.Ultra high pressure, high power and continuous operation2.Good cross-country capability and mobility, suitable for oilfield
Model 2500 Quintaplex Pump Fracturing Truck
Product Explanation:Model 2500(YLC140-1860) fracturing truck is equipped with 2235kW(3000HP) engine and 2085kW (2800HP)quintaplex fracturing pump, which can produce 140Mpa (20000psi)of maximum working pressure. It mainly consists of chassis, deck engine, hydromechanical transmission, quintaplex plunger pump, manifolds, hydraulic/air system and network control system, etc,featuring by ultra high pressure, high power and continuous operation. It is suitable for various fracturing and acidizing operation in intermediate, deep and ultra deep wells.
1. High horsepower engine, chassis-driving fan cooling system, output hydraulic power can be up to 1860 kW (2500HP) with some backup power.
2. Equipped with reinforced side beams. Good cross-country capability and mobility, suitable for oilfield road.
3. Equipped with network control system. The manual or automatic control over one unit or package can be realized.
4. Satellite communication technology for operation data transmission, thus real-time monitoring in other place can be realized.
5. Fitted with multiple automatic safety protection system for the safety of operation.
Main Parameters
Model |
YLC140-1860 |
Max. working pressure |
140 MPa(3-3/4"plunger) |
123 MPa(4"plunger) |
|
97 MPa(4-1/2"plunger) |
|
Max. output displacement |
2172 L/min(3-3/4"plunger) |
2471 L/min(4"plunger) |
|
3128 L/min(4-1/2"plunger) |
|
Rated input power, pump |
2800HP(2085kW ) |
Overall dimensions (LXWXH) |
12500x 2500x4200(mm) |
Total weight |
45000kg |
