Home > Products > solid control system > Oilfield Drilling Mud Decanter Centrifuges for solid control system
Oilfield Drilling Mud Decanter Centrifuges for solid control system
- 200 Set / Sets per Month
- Tianjin Shanghai
- T/T
- LW Series drilling fluid decanting centrifuge for oilfield solid control system
- High quality Drilling Mud Tank For Oilfield
- SJBQ series drilling mud Agitator for oilfield solid control system
- High quality drilling mud Agitator for oilfield solid control system
- Oilfield drilling fluids separator for mud and gas
- 10% discount!!! Gas Liquid Separator for oilfield with high quality
Product Details
Place of Origin: | Shandong, China | Brand Name: | Sinotai | Model Number: | LW Series |
Condition: | New | After-sales Service Provided: | Overseas service center available |
Packaging Details
standard export package or as consumer's request
Product Description
1. LW centrifuge is driven by two motors.
2. The main motor drives the drum and the outer casing of differential through belts while the auxiliary motor, after the differential shifting speed, drives the spiral propeller.
3. This will make the drum and the spiral propeller rotate inthe same direction with a certain differential speed.
Model | LWF450×842N | LWF450×1000N | GLW355×1250N | GLW355x1250 |
Bowl Diameter | 450mm | 450mm | 355mm | 355mm |
Rotary Speed | 1800r/min | 1800r/min | 3200r/min | 0~3200r/min |
G-Force | 815 | 815 | 2035 | 2035 |
Separation point | 5~7μm | 5~7μm | 2~5μm | 2~5μm |
Main Drive | 22kw-4p | 30kw-4p | 30kw-4p | 37kw-4p |
Back Drive | 5.5kw-4p | 7.5kw-4p | 7.5kw-4p | 7.5kw-4p |
Max capacity | ≤40m3/h | ≤60m3/h | ≤40m3/h | ≤40m3/h |
Weight | 2550kg | 2700kg | 2950kg | 3000kg |
Dimension | 2360x1850x1750mm | 2600x1860x1750mm | 2900x1850x1750mm | 2900x1950x1750mm |
Packaging: standard export package or as consumer’s request
Shipping: air transportation, water way transportation, railway transportation, road transportation
1. Reply with 24 hours
2. Specialist online service
3.Wesupply drilling equipment,drilling tools,wellhead tools,down hole tools; Production equipments, Progressing Cavity Pumps, Electrical submersible pump; OCTG, etc.We can also supply the products and service according the special requirement of the customers.
Anne Zhao
Sales representative
Sinotai Petroleum Equipment Co.,Ltd
Address: Dongying Economic Development Zone, Dongying City, Shandong Province, China
Mob:86 18554601089
Tel:86 546 8300512
Fax:86 546 8308512
Skype:anne_sinotai
Web:
Company Profile
As a professional supplier of OCTG, drilling equipment and workover service, Sinotai Petroleum Equipment Co., Ltd. lies in the production base of petroleum equipment and China's second largest oil field --Shengi Oilfield. Our company is a high-tech enterprise in Dongying City with business scope covering the sale, trading, post-sale service and technological development of a wide variety of petroleum equipment.
Besides OCTG, we provide our customers with other drilling and oil recovery equipment like fishing tools, cementing tools, workover rigs, pumping units and OCTG accessories.
The striving target of our company is "Prestige first, Quality supreme; The shortest delivery time, The lowest price, The best quality". Customers' needs are our first priority and customer satisfaction is the bottom line by which we measure our success.
