Specifications
1. Mud agitators2.Easy operation
uce intensity effectively
4. improve work efficiency
5.API spe
Mud agitators
Main feature:
Less than 5.5 kW drilling mud Agitator adopts the blender cycloid speed reducer,and it is applied to the drug liquids mixing tank.
This mud agitator has the advantage of compact structure so it occupies small area.
More than 7.5 kW Mud Agitator uses the turbo and worm gear speed reducer, with the large torque transmission, the revolution is steady, it works reliably and has great merit.
Common model of mud agitator is JBQ5.5kW ,JBQ7.5kW , JBQ11kW and JBQ15kW.
SJBQ Mud Agitator Technical Parameters:
Agitator Model |
SJBQ5.5 |
SJBQ7.5 |
SJBQ11 |
SJBQ15 |
Motor Power |
5.5KW(7.5hp) |
7.5KW(10hp) |
11KW(15hp) |
15KW(20hp) |
Impeller Speed |
60/72RPM |
60/72RPM |
60/72RPM |
60/72RPM |
Impeller Dia(Single) |
600mm |
850mm |
950mm |
1050mm |
Impeller Dia(Double) |
N/A |
Up:750mm |
Up:850mm |
Up:950mm |
Ration |
25:1 |
25:1 |
25:1 |
25:1 |
Dimension(L*W*H) |
870*600*480mm |
906*600*480mm |
1075*650*525mm |
1170*720*565mm |
Shaft Length |
According to tank inner depth |
|||
Electric Specs |
380V/50HZ Or 460V/60HZ Or Customized |
|||
Remarks |
Explosion Proof motor |
|||
