Low Price!! Oilfield Drilling Mud Desander , Oilfield Machinery

Name: Low Price!! Oilfield Drilling Mud Desander , Oilfield Machinery
Brand: SINOTAI
SKU: 119560769
Availability: InStock

US$ 100 - 1,000 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

SINOTAI

Model Number:

Sinotai Petroleum Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai / Tianjin / Qingdao Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name SINOTAI

Model Number QJ

Type Other, desander

Machine Type Drilling Tool

Certification API

Material Stainless Steel

Processing Type Forging

Use Well Drilling

Desander

Main feature:

Desander is the second class and the third class solid control equipment to treat the drilling fluid.
According to the size of the cone diameter, it is divided into desander and desilter.
Usually the cone diameter is more than 6″is called desander, and used as the second-control equipment in drilling operation.
We commonly used 8 "and 10" cones desander to separate solid-phase particle size 47-76μm in the drilling fluids
It apply for directional drilling.

The main technical performance and specification for the desander:

Model	QJ200S	QJ250S	QJ300S	QJ200	QJ250	QJ300
Capacity	≤120m3/h ≤528GPM	≤180m3/h ≤792GPM	≤240m3/h ≤1056GPM	≤120m3/h ≤528GPM	≤180m3/h ≤792GPM	≤240m3/h ≤1056GPM
Cone size	8"	10"	12"	8"	10"	12"
Pressure	0.15~0.35Mpa
Inlet Size	75-100mm	100-150mm	150-200mm	75-100mm	100-150mm	150-200mm
Outlet Size	125-150mm	150-200mm	200-250mm	125-150mm	150-200mm	200-250mm
Separation size	47-76μm		47-76μm		47-76μm
Screen area	1.0m2(600×1600mm)			No Under fluids Shaker
