Specifications
1. LW centrifuge2.drives the drum and the outer casing
3. recycling barite
Specifications
1.High quality of screw propeller and bearings
2.Small vibration and low noise
3.Equipped with VVVF, low energy consumption
Centrifuge
Main feature:
1. LW centrifuge is driven by two motors.
2. The main motor drives the drum and the outer casing of differential through belts while the auxiliary motor, after the differential shifting speed, drives the spiral propeller.
3. This will make the drum and the spiral propeller rotate in the same direction with a certain differential speed.
4. Mainly used for recycling barite to remove small solid, reduce drilling fluid solid content, control the density of drilling fluid viscosity, to ensure that the drilling fluid performance and an important role for fast drilling
Technical Parameters:
Model |
LWF450×842N |
LWF450×1000N |
GLW355×1250N |
GLW355x1250 |
Bowl Diameter |
450mm |
450mm |
355mm |
355mm |
Rotary Speed |
1800r/min |
1800r/min |
3200r/min |
0~3200r/min |
G-Force |
815 |
815 |
2035 |
2035 |
Separation point |
5~7μm |
5~7μm |
2~5μm |
2~5μm |
Main Drive |
22kw-4p |
30kw-4p |
30kw-4p |
37kw-4p |
Back Drive |
5.5kw-4p |
7.5kw-4p |
7.5kw-4p |
7.5kw-4p |
Max capacity |
≤40m3/h |
≤60m3/h |
≤40m3/h |
≤40m3/h |
Weight |
2550kg |
2700kg |
2950kg |
3000kg |
Dimension |
2360x1850x1750mm |
2600x1860x1750mm |
2900x1850x1750mm |
2900x1950x1750mm |
