API Desilter

Name: API Desilter
Brand: Sinotai
SKU: 119556131
Availability: InStock

US$ 5,000 - 20,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Sinotai

Model Number:

QJ series

Sinotai Petroleum Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai qingdao tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Sinotai

Model Number QJ series

Condition New

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. the third class solids control equipment
2. the cone diameter is less than 6aais called desilter
3. 5 inch and 4 inch cone

1.high treatment speed
2.large disposit capacity
3.less energy consumption

Desilter

Main feature:

1. QJ series desilter is the third class solids control equipment

to treat the drilling fluids.

2. According to the size of the cone diameter, they are divided

into desander and desilter.

3. Usually the cone diameter is less than 6″is called desilter,

and used as the third-control equipment in drilling operation.

4. We commonly used 5 "and 4" cone to separate solid-phase

particle size 15-47μm in the drilling fluid.

QJ Desilter Technical Parameters:

Model	ZQJ100S	ZQJ100
Capacity	≤240m3/h (1056GPM)	≤240m3/h(1056GPM)
Screen area	1.0M2 (600*1600mm)	no under fluids shaker
Cone size	4" (Each 4" Cones= 50-75GPM)
Cone number	2-12 Ea cones, specify cones No. when ordering
Pressure	0.20~0.4Mpa	0.20~0.4Mpa
Matching pump	SB4×3-12(11kw) SB5×4-13(30KW) SB6×5-13(37KW) SB8×6-13(55KW)	SB4×3-12(11kw) SB5×4-13(30KW) SB6×5-13(37KW) SB8×6-13(55KW)
Inlet Size	75-150mm
Outlet Size	125-200mm
Separation size	15-20 μm
