Specifications
belt conveyor idler1 Q235 carbon steel tube
2 cema din sans
3 127 102 114 152 14
4 trough return
Industrial carbon steel belt conveyor roller:
Friction adjusting idler is of very strong ability of preventing conveyor belt damage and sideslip. It is based on the friction and friction wheel radian adjusting mechanism to prevent and correct conveyor belt sideslip.
Conveyor Roller Detail:
1. Rubber Roller Dia 50mm-219mm, length 190-3400mm, which are used in the steel industry, harbor, coal industry, power industry, cement industry, etc
2.Tube: Q235
3. Rubber Roller Shaft: 45# STEEL
4.Bearing: Single & Double Row Deep Groove Ball Bearing 2RZ&2Z with C3 clearance.
5. Rubber Roller Seals: Grease retaining inner seal with Multi-stage Labyrinth and Retention Cap with Outboard Rubbing Flinger Seal.
6. Lubrication: Grease is Lithium soap type grease with Rust Inhibitors.
7. Rubber Roller Welding: Mixed gas shielded arc welding end
8. Rubber Roller Painting: ordinary painting, hot galvanized painting, electric static spraying painting, baked painting
Standard:
GB, ISO, CEMA, DIN, JIS, ETC
Production capacity:
as usual 5000 pieces/ week, but urgent order is acceptable
Technical data:
- Tube material: carbon steel pipe
- Tube diameter:89-217 mm
- Tube wall thickness: more than 5 mm
- Tube length: 180-3350mm
- Shaft diameter:20-70 mm or as drawing
- Shaft external length: 10-40 mm on each side or as drawing
- Labyrinth-sealed ball bearing
Advantage:
- Light and rigid frame construction
- Sealing arrangement consist of a double seal
- Additional water proofing neoprene contact lip seal
- Low friction coefficient, waterproof, effective sealing system
- High accurate steel pipes ensure the rollers with low vibration and noise
- Multi-labyrinth seals achieve waterproof and dustproof
- Adopting good bearing make sure the lifetime, stable running and good quality
- Excellent lubricating property
Lixian Huadu Rubber Belts Co., Ltd. is a professional supplier of rubber products, located near to Beijing & Tianjin. We are near to Beijing-Guangzhou & Beijing-Kowloon railways and Beijing-Shenzhen Expressway, enjoying convenient transportation.
Since inception, we have introduced advanced production equipment and testing instruments, and strived to produce high quality rubber products. Our main products are: a variety of general conveyor belts, steel cord conveyor belts, flat belts, etc. Our products are sold to more than 31 large and medium-sized cities and regions, well received by consumers.
Our company insists on "Quality is Life". We won titles like "Trustworthy Unit" & "Product Quality Trustworthy Enterprise". We have has a high reputation in the industry. We warmly welcome friends to cooperate with us to create a brilliant tomorrow.
Our Company:
Testing:
Certification:
1.Is OEM available?
Yes, OEM is available. We have professional designer to help your brand promotion.
2.Is the sample available?
Yes, samples are available for you to test the quality.If we have samples in warehouse,freight can be paid by your side.
3.Are the products tested before shipping?
Yes, all of our rubber belt ,conveyor belt was qualified before shipping. We test every batch every day.
4.What’s benefit will you bring?
Your client satisfied on the quality.
Your client continued orders.
Your can get good reputation from your market and obtain more orders.
For more details,please inquiry us!
Polyester conveyor belt, (EP)
Nylon conveyor belt, (NN)
Cotton conveyor belt, (CC)
Sidewall conveyor belt (SW)
Chevron conveyor belt, (C5 C10 and C15)
Oil Resistance conveyor belt, (OR and MOR)
Hot Resistance conveyor belt, (HR)
Fire Resistance conveyor belt, (FR/PVC/PVG)
Heat Resistance conveyor belt, (OHR/ OFR)
Cold Resistance conveyor belts, (CR)
Endless belts
Conveyor roller, idler
Conveyor Pulley, frame,bracket etc
WELCOM TO INQUIRY US.
