API 11AX 30-175 THM Sucker Rod Pump for 3-1/2" Tubing

Name: API 11AX 30-175 THM Sucker Rod Pump for 3-1/2" Tubing
Brand: SINOTAI
Price: USD $2,000 - 6,000 / Set

FOB Price

USD $2,000 - $6,000 / Set

1 Set(Min.Order)

Supply Ability 20 Set / Sets per Month
Port Shanghai Tianjin
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	China	Brand Name:	SINOTAI	Model Number:	Sucker Rod Pump (Tubing Type)
Theory:	Vacuum Pump	Structure:	Piston Pump	Usage:	Oil
Power:	Electric	Standard or Nonstandard:	Standard	Fuel:	Other
Pressure:	High Pressure	Application:	Submersible

Packaging Details

Standard Package or as your requirement

Product Description

Specifications

Tubing type Sucker Rod Pumping
Tubing: 3-1/2"
type: machanical, heavy wall,
API 11AX
Flow :2.235 m3/d

Sucker Rod Pump (Tubing Type)

The barrel assembly and the standing valve assembly of the pump can be mounted and connected to the tubing on the ground, which are run into the well first, then connect the plunger assembly with the lower end of the sucker-rod and run them into the pump.
Tubing pump has the characteristics as large flow rate, tight and sound structure.
Standing valve has two types: non-pullable and pullable. The pullable standing valve tubing pump has cup type and mechanical type.

Technical Specifications:

Pump Specification	Pump Bore(in)	Length of Plunger	Range of Stroke(mm)	Flow Rate (m³/d)	Size of matched tubing(in)	Size of connecting Sucker Rod(mm)	Length of extension Coupling
25-125	1.250	600-1200	600-12000	1.140	2-1/2 2-7/8	16	300-900
25-150	1.500			1.642	2-1/2 2-7/8	16
25-175 20-175	1.750			2.235	2-1/2 2-7/8	16
25-225	2.250			3.694	2-7/8	19
25-275	2.750			5.518	2-7/8	22
30-275	2.750			5.518	3-1/2	22
30-325	3.250			7.707	3-1/2	22
30-375	3.750			10.261	3-1/2	25
40-375	3.750			10.261	4	25
50-475	4.75			16.75	5-1/2	28.57

3-1/2
