1.Main Parameter:
. Measure Range:
Carbon: w(C) 0.0001%-6.0000% (can be extended to 99.99%)
Sulphur: w(C) 0.0001%-0.5000% (can be extended to 99.99%)
. Analysis Error:
Carbon: accord with ISO9556 standard
Sulfur: accord with ISO4935 standard
. Time of analysis:
25 to 60 seconds, could be adjusted. Around 35 seconds usually
. Electronic balance:
Weighing range: 0-120g
Precision of read: 0.0001g
. High frequency furnace:
Power: 2.2KVA
Frequency: 20MHz
.
2.Analyzing software
Operating software: |
Adopt Deliph software,WINDOWS XP full Chinese operation interface. |
Analyzing route way: |
With channel management function, carbon and sulfur channel can increase, delete and edit separately without quantity limit. Preset low carbon and high sulfur interface. |
Analyzing function: |
Dynamic data accumulation when analyzing, 20times sampling per second, increasing the sensitivity and accuracy. With sample management function, can edit the name, mark of sample, also can do adding and deleting sample name. |
Display function: |
Separately curve frame for Carbon & Sulfur, dynamic show the data and Carbon & Sulfur release curve. |
Data processing function: |
Analysis results store by ACCESS data-base way, it can store data and curve every time; can search the results according to time, operator, sample name and mark any time; with curve/data storage, deduction of blankness, preset of parameters, channel selection, data statistic, result adjustment and curve preparing and other function. Can realize creating carbon and sulfur working curve and do the curve fitting in the software. |
Printing function: |
Printing mode diversification: Laboratory and inspection station printing mode and can self-design proper mode. |
Self-diagnose function: |
System self-diagnose function,can realize checking furnace head and sealing performance of the gas chamber by the soft ware. |
3. Scope of Supply
One set of CS-8820 Carbon & Sulfur Analyzer includes the following components:
Item |
Component parts |
Quantity |
1 |
Main body of CS-8820 Type High-frequency Infrared Carbon & Sulfur Analyzer |
1 |
2 |
WF-T88 Type High frequency inductive combustion furnace |
1 |
3 |
SDSL (Sartorius) BS124S Electronic balance |
1 |
4 |
Tsinghua Tongfang commercial micro computer |
1 |
5 |
P1007 HP laser printer |
1 |
if you have any furtuer questions,please do not hesitate to contact us.
