Specifications
1.stable and reliablecontinuously
3.Short and portable
SKJ-1 Electronic Pressure Gauge
Application Areas
SKJ-1Electronic Pressure Gauge is a electronic memory pressure gauge. This pressure gauge is mainly applied to testing and recording of downhole pressure and temperature of various oil wells and water wells. It can also be used for test of flowing pressure and pressure build-up as well as annulus testing.
Features
1. Imported principal part of the instrument is stable and reliable.
2. Power consumption is extremely low and the pressure gauge can work continuously for two years.
3.The maximum memory capacity is 28560 groups of data.
4. It uses non-rechargeable batteries and works stably.
5. Different modes of starting up for the convenience of customers.
6. Short and portable.
7.No additional battery or power supply is needed when communicating with a computer. This helps to make the operation simple and reduces the power consumption of batteries.
Technical Specifications
Pressure measuring range (MPa) |
0~60 |
Pressure accuracy (F.S) |
0.05,0.1 |
Temperature measuring range(°C) |
125 |
Temperature measuring uncertainty(°C) |
0~125 |
Maximum working temperature |
±1 |
Memory capacity(group) |
28560 |
Dimensions (diameter×length mm) |
Φ25×493 |
