SZJ-1 Multi-parameter Drilling Instrumentation System

SZJ-1 Multi-parameter Drilling Instrumentation System thumbnail-1
SZJ-1 Multi-parameter Drilling Instrumentation System photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
sinotai
Place of Origin:
China
Contact Supplier Request Quote Chat Now
Sinotai Petroleum Equipment Co., Ltd.
Silver Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
main ports
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name sinotai
Place of Origin China

SZJ-Ⅰ Multi-parameter Drilling Instrumentation System



1.Making use of mechanism and electronics, and employing world-class programmed processing technology, the system can group any number of parameters into various instrumentation configurations.



2. Values of parameters can be recorded, displayed and plotted by indoor computer system but also recorded by conventional weight indicator.



3. Easy and convenient move, installation and uninstallation are guaranteed by special cables that are corrosion-resistant,oil-proof, water-proof, fire-resistant, low temperature resistant and salt-fog resistant, and by sealed, waterproof and explosion-proof aerial connectors.



Parameters

Measuring Range

Accuracy

Response time

Maximum Installation Distance

Hookload and WOB

0~500×10kN

±2F.S



Rotary torque

0~40kN·m
(Display mode;0~500scale)

±5F.S



Tong torque

0~100kN(in tail line pull)

±2.5F.S



Mud pressure

0~40MPa

±1.5F.S



Depth

0~9999.9m



RPM

0~300r/min



SPM of Pump 1 and 2

0~300storkes/min



Mud flow

0~100

±2F.S



Mud density

0.8~2.0g/cm3

±0.02g/cm3



Total gas

0~100LEL(lower limit explosive concentration)

±5LEL(F.S)

<15seconds
(90response)

1000m

H2S

0~100ppm

±5F.S

<60seconds

1000m

Working temperature

-30~70°C



Relative humidity

0~90



Mud pit volume

0~999.9m3



Working voltage

220VAC±10,47~63Hz
