Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Sheet & Plate > SPA-H Container Steel

SPA-H Container Steel

Name: SPA-H Container Steel
Brand: STECH
SKU: 119539335
Availability: InStock

US$ 450 - 550 MOQ: 50 Metric Tons

Key Specifications

Get Latest Price

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Grade:

SPA-H

Thickness:

5~60mm

Contact Supplier Request Quote Chat Now

Wuhan Genprior Enterprise Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Main port in China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard AISI, ASTM, BS, DIN, GB, JIS

Grade SPA-H

Thickness 5~60mm

Place of Origin Hubei, China

Brand Name STECH

Model Number SPA-H

Type Steel Plate

Technique Hot Rolled

Surface Treatment Other, Alloy steel plate

Application Container Plate

Special Use High-strength Steel Plate

Width 1500~3000

Length 5800~12000

SPA-H Container Steel

Container Steel Introduction

A special rolling unit for centralized rolling has been established in the production process of this series of products. The key technical parameters are strictly controlled and managed. The physical indicators of quality are much higher than the corresponding values of the JIS standard. The addition of rare earth microelements has improved the form of harmful inclusion such as sulfide, so that SPA-H & SM490A steel has an excellent cold-bending processability. The accuracy to thickness of the steel plates is high and the difference between vertical thickness and horizontal thickness is small. The steel plates have good shape and surface quality after rolling and levelling. The use of converter in steel-making and in-mold feeding rare earth wire pouring in continuous casting has make the steel clean with low content of P&S.

Available Steel Grade, Delivery Standard & Function

Steel Grade	Delivery Standard	Function
SS400	JIS G3101	Applied to manufacturing bottom plates and bottom rims of containers
SM490A	JIS G3106	Applied to manufacturing studs, doors and roofs of containers
SPA-H	JIS G3125	Applied to manufacturing panels, side plates and rims of containers

Product Size

Steel Grade	Sheet Sheet mm	Steel Coil mm	Steel Strip mm
SPA-H	1.6~8.0 x 900~2100 x 3000~16000	1.6~8.0 x 900~2100 x C	1.6~6.0 x 120~750 x C
SM490-A
SS400

Size & Appearance Tolerance: as per JIS G3193

Size can be Customized if large quantity

Chemical Composition (Wt%)

Steel Grade	C	Si	Mn	P	S	Cu	Cr	Ni
SS400	-	-	-	≤0.050	≤0.050	-	-	-
SM490A	≤0.20	≤0.55	≤1.60	≤0.035	≤0.035	-	-	-
SPA-H	≤0.12	0.25~0.75	0.20~0.50	0.07~0.15	≤0.040	0.25~0.60	0.30~1.25	≤0.65

Mechanical Property

Steel Grade	Plate Thickness mm	Yield Strength Rel MPa	Tensile Strength Rm MPa	Elongation A %		180o Cold Bend Test d=Bend Diameter a=Sample Thickness b=35mm
Steel Grade	Plate Thickness mm	Yield Strength Rel MPa	Tensile Strength Rm MPa	Sample	Value
SS400	≤5.0	≥245	400~510	#5	≥21	d=3a
SS400	>5.0~≤8.0	≥245	400~510	#1A	≥17	d=3a
SM490A	≤5.0	≥325	490~610	#5	≥22	-
SM490A	>5.0~≤8.0	≥325	490~610	#1A	≥17	-
SPA-H	≤6.0	≥345	≥480	#5	≥22	d=a
SPA-H	>6.0	≥355	≥490	#1A	≥15	d=3a
