Specifications
1,Fashion design, compacted structure,2,Easy installation,Energy-saving
3,Excellent quality and competitive price
Indoor side-mounted HV vacuum circuit breaker
ZN85 (VKP) indoor side-mounted HV vacuum circuit breaker
General
ZN85 (VKP) indoor side-mounted HV vacuum circuit breaker is the indoor equipment of three-phase, AC 50Hz, rated voltage 12KV which can be applies to industry and mining enterprises, power plant and substation as control and protect the electric equipments. The products comply with the standard of GB1984-20 (AC HV circuit breaker), JB/T3855-1999 (3.6-40.5 KV indoor HV vacuum circuit breaker, DL/T402-1999 (HV vacuum circuit breaker ordering technique) and IEC 6271-100:2001 (AC HV circuit breaker)
ZN-12(VKP) side-mounted HV vacuum circuit breaker is fixed installed, which is used to fix the switch cabinet. The circuit breaker can be singly used, or can be used in ring net, packing substation and other non-standard power supply system. The circuit is long used, easy maintained, pollution-free, explosion-free, low noise.
