Help CenterCZT Series Hydraulic Makeup and Breakout Machine
Related Products
-
CZT Series Hydraulic Bucking MachineUS$ 100,000 - 300,000MOQ: 1 Set -
CZT Series Casing and Tubing Coupling Bucking UnitsUS$ 100,000 - 300,000MOQ: 1 Set
-
8 5/8REG Drill CollarNegotiableMOQ: 1 Piece
-
CZT Oilfield Make-up and Breaking-out MachineUS$ 100,000 - 300,000MOQ: 1 Set
-
CZT Series Oilfield Bucking Units (2-3/8"-11-2/5" Pipes)US$ 100,000 - 300,000MOQ: 1 Set
Specifications
1.CZT hydraulic makeup and breakout machine 2 used for assembling, dismantling pipes and downhole tools 3.highly automaticCZT series of hydraulic bucking unit
CZT series of hydraulic bucking unit is based on our absorption of advanced technique of similar products both home and abroad, and combination of present application situation and characteristic of china's oil industry. it is specially used for assembling, dismantling and maintaining many different kinds of drilling and down hole tools.
1. Features
(1).Full hydraulic action, high degree of automation ;
(2). big torque for screwing on and crewing off can be freely adjusted continuously;
(3).wide application range of pipe diameter;
(4). Non-slip, no damage to the workpiece surface;
(5). Speedup spinning, pushing and pulling;
(6). Six radial cylinders, act synchronously, clamping force is uniform distribution.
2. Unit configuration
It is consisted of 7 main parts, hydraulic control console, stationary clamp, movable clamp, rapid turnbuckle device, auxiliary support equipment, base, hydraulic push-pull device of tailstock.
3. Parameter List
Items |
English |
Metric |
Applicable Pipe Diameter |
23/8-112/5in |
60-290mm |
Screwing On/Off Torque, Max |
84818ft·Lbs |
115kn·M |
base Length |
59ft |
18,000mm |
Rapid Turnbuckle Torque, Max |
2950ft·Lbs |
4.0kn·M |
Thrust, Max |
25tons |
246kn |
Tension, Max |
20tons |
196kn |
Host Specification |
5.57"X5.57"X59" |
1700x1700x18000mm |
Net Weight |
17637lbs |
8000kg |
