Home > Industrial Equipment & Components > Compressor > Compressor Unit > 75HP INDUSTRIAL SCREW AIR COMPRESSOR(GS-0221Q)

75HP INDUSTRIAL SCREW AIR COMPRESSOR(GS-0221Q)

Name: 75HP INDUSTRIAL SCREW AIR COMPRESSOR(GS-0221Q)
Brand: 75HP INDUSTRIAL SCREW AIR COMPRESSOR
SKU: 119528313
Availability: InStock

75HP INDUSTRIAL SCREW AIR COMPRESSOR(GS-0221Q) thumbnail-1

75HP INDUSTRIAL SCREW AIR COMPRESSOR(GS-0221Q) photo-1

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Taiwan, China

Brand Name:

75HP INDUSTRIAL SCREW AIR COMPRESSOR

Model Number:

GS-0221Q

Contact Supplier Request Quote Chat Now

Golconda Source Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

TAIWAN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Taiwan, China

Brand Name 75HP INDUSTRIAL SCREW AIR COMPRESSOR

Model Number GS-0221Q

Voltage 55KW/ 75HP

Dimension(L*W*H) L 1,690 * W 1,100 * H 1,850 MM

Weight 1290 KGS

GS-0221Q 75HP INDUSTRIAL SCREW AIR COMPRESSOR

DESCRIPTION

* F.A.D. OF WORKING PRESSURE:

- 7 BAR: 9.50 M³/MIN; 336 CFM.

- 10 BAR: 8.20 M³/MIN; 289 CFM.

- 13 BAR: 6.80 M³/MIN; 240 CFM.

* MOTOR POWER: 55KW/ 75HP.

* AIR OUTLET PIPE DIAMETER: 2”

* COMPRESSOR DIMENSIONS:

L 1,690 × W 1,100 × H 1,850 MM.

* NET WEIGHT: 1,290 KGS.

* FEATURES:

- TEMPERATURE CONTROL SYSTEM: ONCE OIL TEMPERATURE EXCEED THE VALUE SET (STANDARD 70^OC/158^OF), THE CONTROL ACTIVATES, PART OF OIL FLOW PASSES THROUGH COOLER. IF IT REACHES A VALUE ABOUT 15^OC HIGHER, OIL VALVE CLOSES, ALL OIL PASSES THROUGH COOLER.

- OIL/ AIR SEPARATOR SYSTEM: Effective separation of oil and vapor, air discharged is clean with oil content below 2 ppm.

- COOLING SYSTEM: For markets with 38~40^oC and humidity 70~100%, we provide enlarged cooler suitable for ambient temperature 50^oC. It is 30% larger than AKG original design.

- INTAKE CONTROL: Allows for a closed inlet to reduce the starting load.
