Help CenterMKDS-420 Automatic Packing Machine
Related Products
-
MKDS-520 Automatic VFFS Vertical Form Fill Sealing Machine From Professional ManufacturerUS$ 23000.00 - 28000.00MOQ: 1 Piece -
MKDS-720 Stainless Steel Corn Flakes Automatic Packaging MachineUS$ 23000.00 - 28000.00MOQ: 1 Piece
-
MKDS-820 Large Vertical Automatic Packing MachineUS$ 23000.00 - 28000.00MOQ: 1 Piece
-
MKDS-52OT Hot Quadrilateral Powder Packing MachineUS$ 23000.00 - 28000.00MOQ: 1 Piece
-
MKDS-72OTStainless Steel Automatic Vertical Form Fill And Seal MachineUS$ 23000.00 - 28000.00MOQ: 1 Piece
Type: MYD-380/420/520/720
System composition: chain bucket elevator / vertical packaging machine / product conveyor.
Scope of application: semi automatic packing machine for conveyor feeding through artificial feeding way, mainly suitable for packing various single volume is larger, can not use the automatic weighing machine special products or filling machine of certain weight such as fried chicken, cheese, jelly beans, fruit, candy, teeth etc..
Characteristic:
Artificial feeding mode, economical and practical.
Packaging machine, conveyor are stainless steel and carbon steel models optional, suitable for a variety of needs.
According to the characteristics of different materials for conveyor assembly tablet hopper or pattern plate of the hopper.
Technical characteristics:
Chinese screen display, intuitive, simple.
PLC computer control system, more stable operation, can not stop to adjust any parameters.
Can store ten sets of parameters, the replacement of varieties more accurate.
Servo motor drawing film, more accurate positioning.
Independent temperature control system, the precision can reach - 1 degrees C.
Independent control of the transverse and longitudinal sealing temperature, good for all kinds of composite film, PE film and other packaging materials.
Packing type diversification, back seal, inserted angle, even bag, punching etc..
Bag making, sealing, packaging, print date in one.
Clean working environment, low noise.
Technical characteristics:
1.In English membrane touch screen display, intuitive, simple.
2.PLC computer control system, more stable operation, can not stop to adjust any parameters.
3.Can store ten sets of parameters, the replacement of varieties more accurate.
4.Servo motor drawing film, more accurate positioning.
5.Independent temperature control system, the precision can reach - 1 degrees C.
6.Independent control of the transverse and longitudinal sealing temperature, good for all kinds of composite film, PE film and other packaging materials.
7.Packing type diversification, back seal, inserted angle, even bag, punching etc..
8.Bag making, sealing, packaging, print date in one.
9.Clean working environment, low noise.
The applicable range of packaging:
With a variety of metering device, packaging can be of different materials.
Technical parameters :
| Type | MKDS-420 |
| Bag length | 80-300mm(L) |
| Bag width | 50-200mm(W) |
| Max width of roll film | 420mm |
| Packing speed | 5-60bags/min |
| Measuring range | 150-1200ml |
| Air consumption | 0.65mpa |
| Gas consumption | 0.3m³/min |
| Power voltage | 220V |
| Power | 2.2KW |
| Dimension | (L)1320mm×(W)950mm×(H)1360mm |
| Deadwight of machine | 540Kg |
Q1.Are you a manufacturer or a trading company ?
A:
We are a professional manufacturer of Pre-packing and after-packaged machine.
Q2.Where is your factory located ? How can I visit there ?
A:
Our factory is located in Shanghai City. From Pudong airport or Hongqiao airport
Q3.How to support me if i don't know how to use it?
A:
Free training within the warranty by tel and mail or skype. We also can dispatch our
technician to customer’s company if customer agree the air ticket and hotel.
Q4.What's the pre-sale service of your company?
A:
Professional Advice about Market, machines, processing , materials, packing can be supplied.
Q5. What's the after-sale service of your company?
A:
1. Allocation chart
2. Operation manual
3. One year warrantee, life time maintenance with cost price.
4. Free easy broken spare parts
5. First installation can be done by engineer.
6. Training workers in customer’s factory.
Q6. If machines wearing parts need changing, what should we do?
A:
We can offer the wearing parts all the time, and offer video.
Q7. What's the payment terms if we want to buy the machines?
A:
L/C, 100%T/T,T/T 30% down payment, 70% balance before delivery.
