Widely used Co2 Laser Cutting Cloth machinery
Widely used Co2 Laser Cutting Cloth machinery can be applied to various nonmetal materials, cutting and engraving speed and effect is very good. This machine is welcomed for its good work, high speed and low cost.
| Materials | Cut | Engrave |
| Acrylic, Plexiglass, Pmma, Perspex, Double Color plate, ABS board | Yes | Yes |
| Plastic, PP, PET, PC, PMMA, PS, PES, PA, Plastic Foils&Films, Polycarbonate, polyester or polyimide membrane keyboards |
Yes | Yes |
| Wood, Bamboo, Veneer, MDF, Blasa wood, Plywood | Yes | Yes |
| Leather, Pig leather, Cow leather, Sheep Leather | Yes | Yes |
| Textile, Cotton, Silk, Felt, Lace, Synthetic & technical textiles, aramid | Yes | Yes |
| Foam & Filter, Mats Polyester (PES), Polyethylene (PE), Polyurethane (PUR) Neopren |
Yes | Yes |
| Paper, Cardboard, Chipboard, Press board | Yes | Yes |
| Stone, Ceramic, Granite, Marble, Natural Stone, Pebble Stone, Slate | No | Yes |
| Rubber, Synthetic % Silicone Rubber, Natural Rubber, Microporous foam, Silicone Rubber, Synthetic Rubber |
Yes | Yes |
| Glass, Pressed glass, Float Glass, Crystal Glass, Mirror glass | No | Yes |
Widely used Co2 Laser Cutting Cloth machinery Specifications as following:
Model |
LP-C1610 |
Working area |
160cm*100cm / 63in*39in |
Equipment Dimension |
195cm*141cm*107cm/77in*55in*42in (L*W*H) |
Laser power |
60W/80W/100W/150W (optional) |
Laser type |
CO2 sealed laser tube, water-cooled, 10.6um |
Cooling type |
Water cooling |
Engraving speed |
0-70000mm/min |
Cutting speed |
0-40000mm/min |
Communication interface |
USB |
Control system |
Ruida Controller |
Laser output control |
1-100% software setting |
Smallest Character Engraving |
English 1.0mm*1.0mm |
Locating Precision |
≤±0.01mm |
Highest Scanning precision |
2500DPI |
Operating temperature |
0 - 45°C |
Power supply |
220V/50HZ , 110V/60HZ |
Graphic format supported |
BMP, PLT, DST, DXF, AI |
Software supported |
ArtCut, PhotoShop (Conversion output) CorelDraw, AutoCAD, Lasercut (Direct output) |
Work table |
Honeycomb Work table |
Driving system |
3 phases stepper motor |
1. 24 Months for Machine
2. 10 Months for Reci Laser tube, and 6 month for other tube , lens and mirror
3. 12 Months for equipment outside, such as water pump, fan, air pump,etc.
4. Detailed manual and video to guide the user how to use the machine and maintenance, also supply the specs settings for the speed and power to engrave or cut on various material. Lifely and fast technical guide and solution within 24hours by email and web camera.
