1W LED SMD Type 5050

Name: 1W LED SMD Type 5050
Brand: NPT, AAA
SKU: 119506037
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

NPT, AAA

Model Number:

NPT1W1405565D

Novel Power Technologies Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name NPT, AAA

Model Number NPT1W1405565D

Type LED

Package Type Surface Mount

Max. Forward Voltage 3.0~3.4V

Max. Reverse Voltage 5V

Max. Forward Current 700mA

Max. Reverse Current 10uA

Specifications

High Power LED in SMD package. Wide viewing angle, suitable for home lighting, commercial applications.

Features:

1. Bridgelux, Epistar chips

2. Voltage: 3.0~3.4V

3. Current: 350mA, Maximum 700mA

4. Brightness: 140~150lm

5. Color Temperature: 2700K~3300K (warm white), 4000K~4500K (Neutral white). 5500K~6500K (Cool White)

6. Viewing angle: 160 degree

7. Available color: White, Red, Amber, PC Amber, Blue, Green

8. RoHS compliant.

9. Warranty 3 years

Typical Parameter at Ta=25°C T_j≤100°C I_F=350mA
Part Number	Emitting Color	color temperature Tc(K) / Wave Length (nm)	Lens Type		Forward Voltage V_f(V)		Luminous Flux(lm)	Viewing Angle(°)
NPT1R0406263D	Red	620~630	Water Clear		1.9~2.4		40~50	155±5
NPT1Y0405859D	Amber	585~595	Water Clear		1.9~2.4		40~50	155±5
NPT1D0705858D	PC Amber	580~585	Water Clear		3.2~3.6		70~80	155±5
NPT1B0254647D	Blue	460~470	Water Clear		3.2~3.6		25~35	155±5
NPT1G0905253D	Green	520~530	Water Clear		3.2~3.6		90~100	155±5
NPT1W1405565D	White	5500~6500	Water Clear		3.0~3.4		140~150	155±5
NPT1W1402733D	Warm White	2700~3300	Water Clear		3.0~3.4		140~150	155±5
Absolute Maximum Ratings at Ta=25°C
Parameter				Symbol		MAX		Unit
Power Dissipation				P_D		1200		mW
Peak Forward Current (1/10 Duty Cycle 0.1ms Pulse Width)				I_FP		700		mA
Reverse Voltage				V_R		5		V
Reverse Current				I_R		≤10		μA
Operating Temperature				T_opr		-25~100		°C
Storage Temperature				T_spr		-40~100
Lead Soldering Temperature(5mm From The Base Of The Epoxy Bulb)				Tsol		260≤5s		°C
