Street Light LED

Name: Street Light LED
Brand: NPT,AAA
SKU: 119505223

Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

NPT,AAA

Model Number:

NPT10W7005565

Novel Power Technologies Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China Shen Zhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name NPT,AAA

Model Number NPT10W7005565

Specifications

High Power LED specially designed for street lighting. 10W and above, good thermal performance, long lifetime, lower power loss.

High Power LED 10W

Features:

1. Voltage: 9.6~10.8V

2. Current: 1050mA, Maximum 1200mA

3. Brightness: 700~800lm

4. Color Temperature: 2700K~3300K (warm white), 4000K~5500K (Neutral white). 5500K~8000K (Cool White)

5. Viewing angle: 160 degree

6. Available color: White, Red, Yellow, Blue, Green

7. RoHS compliant.

Typical Parameter at Ta=25°C T_j≤80°C I_F=1050mA
Part Number	Emitting Color	color temperature Tc(K) / Wave Length (nm)	Lens Type		Forward Voltage V_f(V)		Luminous Flux(lm)	Viewing Angle(°)
NPT10R2706263	Red	620~630	COB		6.0~7.8		270~360	160±5
NPT10Y2705859	Yellow	585~595	COB		6.0~7.8		270~360	160±5
NPT10B0904647	Blue	460~470	COB		9.6~10.8		90~135	160±5
NPT10G5405253	Green	520~530	COB		9.6~10.8		540~630	160±5
NPT10W7005565	White	5500~6500	COB		9.6~10.8		700~800	160±5
NPT10W7002733	Warm White	2700~3300	COB		9.6~10.8		700~800	160±5
Absolute Maximum Ratings at Ta=25°C
Parameter				Symbol		MAX			Unit
Power Dissipation				P_D		10.8			W
Peak Forward Current (1/10 Duty Cycle 0.1ms Pulse Width)				I_FP		1200			mA

Reverse Voltage				V_R		5			V
Reverse Current				I_R		≤10			μA
Operating Temperature				T_opr		-25~85			°C
Storage Temperature				T_spr		-40~100
Lead Soldering Temperature(5mm From The Base Of The Epoxy Bulb)				Tsol		260(≤5s)			°C
