Miniature 1W Power LED

Name: Miniature 1W Power LED
Brand: NPT, AAA
SKU: 119505233

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

NPT, AAA

Model Number:

NPT1W1105065E-M

Novel Power Technologies Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name NPT, AAA

Model Number NPT1W1105065E-M

Type LED

Package Type Surface Mount

Max. Forward Voltage 3.2~3.6

Max. Reverse Voltage 5

Max. Forward Current 0.4

Max. Reverse Current 10uA

Specifications

Miniature 1W LED with heat sink

High Power LED 1W

Features:

1. Voltage: 3.2~3.6V

2. Current: 350mA, Maximum 400mA

3. Brightness: 110~120lm

4. Color Temperature: 2700K~3300K (warm white), 5000K~6500K (Neutral white). 6500K~8000K (Cool White)

5. Viewing angle: 120 degree

6. Available color: White, Red, Yellow, Blue, Green

7. RoHS compliant.

Typical Parameter at Ta=25°C T_j≤80°C I_F=350mA
Part Number	Emitting Color	color temperature Tc(K) / Wave Length (nm)	Lens Type		Forward Voltage V_f(V)		Luminous Flux(lm)	Viewing Angle(°)
NPT1R0306263S-M	Red	620~630	Water Clear		2.0~2.6		30~40	115±5
NPT1Y0305859S-M	Yellow	585~595	Water Clear		2.0~2.6		30~40	115±5
NPT1B0154647S-M	Blue	460~470	Water Clear		3.2~3.6		15~25	115±5
NPT1G0605253S-M	Green	520~530	Water Clear		3.2~3.6		60~70	115±5
NPT1W1106580S-M	White	6500~8000	Water Clear		3.2~3.6		110~120	115±5
NPT1W1002733S-M	Warm White	2700~3300	Water Clear		3.2~3.6		100~110	115±5
Absolute Maximum Ratings at Ta=25°C
Parameter				Symbol		MAX			Unit
Power Dissipation				P_D		1200			mW
Peak Forward Current (1/10 Duty Cycle 0.1ms Pulse Width)				I_FP		400			mA

Reverse Voltage				V_R		5			V
Reverse Current				I_R		≤10			μA
Operating Temperature				T_opr		-25~80
Storage Temperature				T_spr		-40~100
Lead Soldering Temperature(5mm From The Base Of The Epoxy Bulb)				Tsol		260≤5s
