digital single yarn tensile strength tester
Applicable Range
Used for testing the breaking strength and elongation percentage of various cotton, wool, linen, silk, chemical fiber, core-spun single yarn, pure or blending natural or chemical fiber yarns.
Standards
ISO2062, ASTM D2256, BISFA-2004,BISFA-1997
GB/T14344: Testing method for tensile of man-made filament yarns
GB/T3916: Textiles--Yarns from packages--Determination of single-end breaking force and elongation at break
Technical parameters
1.Working pattern: ISO kinetic elongation (CRE) principle, computer control, LCD display, printing out
2.Testing range: 1%~100% of the full range, 3000cN, 5000cN.
3.Testing accuracy:≤0.2%F·S
4.Tensile speed:10~1000mm/min
5.Max.elongation:400±0.1mm
6.Clamps distance:100mm, 250mm, 500mm
7.Pre-tension:0~150cN tension scale
8.Power source: AC 220V±10% 50Hz 0.1kW
9.External dimension:370×530×930mm
10.Weight:60kg
