high price and high lumens led rigid bar with lens
Packaging & Delivery
| Packaging Detail: | LED Light Bar ( inner box + outer box ) |
| Delivery Detail: | LED Light Bar order 10-25 days ( sample 5-7 days ) |
high price and high lumens led rigid bar with lens
|
Description: Series Direct-lit light bar features outstanding lumen output with low power consumption. With secondary optical lens on LED, the emitting angle can be widened so that the light bar presents excellent light uniformity.
Direct-lit light bar is an energy-saving and high efficient solution for TV backlight, panel light and advertising light box |
Constant Current or Constant Voltage for option
Part Number |
Dimensions Net weight |
LED QTY |
Test Current Test Voltage Power |
Luminous flux |
Efficacy |
TCP Test |
Comment |
YL-SW233 |
1100x18x7.2mm 120g |
22pcs |
300mA 17.3V 5.2W |
730Lm |
140Lm/W |
33 °C |
0 ohm resistor Requires CC driver |
|
660mA 18.5V 12.2W |
1400Lm |
115Lm/W |
40 °C |
||||
YL-SW213 |
1100x18x7.2mm 120g |
22pcs |
24V 15.5W |
1390Lm |
90Lm/W |
40 °C |
Easy to Expand |
|
Note: Beam Angle 160 °, Tolerance range for optical data: ±10 %. Tolerance range for electrical data±5 % The above data testing at room temperature is 25 °C, Cooling by free air convection. TCP test Temperature Max 40 °C, Test LED color temperature 5800-6250K, CRI>80, (WW2800~3200K 95% brightness ; NW3800~4200K 98% brightness) | |||||||
Company Information
Shenzhen YIGAO Optoelectronics CO., LTD. is a high-tech company engaged in researching, manufacturing,marketing and selling LED light source since 1995.
Since 2005, we have developed the market share successfully in North America, South America, Eastern Europe, Africa, Middle East, Southeast Asia and some other international markets. In accordance with our overseas customers’ requirements and using international advanced technology, our products have reached international standards. This was highly appreciated by our local and international customers.
