Wireles Network Camera Wifi IP Camera WithP2P Supported.
- Shenzhen
You May Like
-
Children's Smart Watch Gps Tracker
-
Latest IOS Smart Watch Waterproof Smart Watch SOS Kids Gps Watch
-
New Design Gps Kids Tracker Watch With SOS for Smartphone Smart Watch
-
2015 New Children Smart Shoes With GPS Tracker Position Function Quality Choice
-
2015 New Sport Smart Shoes With GPS Tracker Position Function ODM or OEM Quality Choice
-
Kid's GPS School Bag With Free Tracking and Software for Android/iphone
Product Details
| Place of Origin | China | Brand Name | Aoya | |
| Model Number | camera_C86 | Type | Digital Camera | |
| Style | Box Camera | Sensor | Other, CMOS, CMOS,1/4'' 1.0 Megapixel CMOS | |
| Technology | NetWork | Special Features | Other, Mobile alarm |
Product Description
>Dual stream H.264 1/4" Color CMOS Sensor 1.0 Megapixel
>Resolution: 720P: 1280*720@30fps
>12* IR LEDs make 15m night vision.
>Suport QR Code Scanning.
> Build-in TF card slot, Max 32GB
>Build-in Microphone & Speaker, supporting two-way audio intercom
>Alarm push technology-Compatible with a variety of wireless smoke/gas detector,door magnetic
Support 64 alarm input and max. 8 zones. Camera gives alarm when alarm triggered
>P2P(Plug&Play)technology,penetration degree can be 99%,applicable toany
>Pan/Tilt control: Pan:355°& Tilt:120°
>Mobile Monitor: iPhone(APP Store),Android
>Wi-Fi compliant with wireless standards IEEE 802.11b/g/n
>support TCP/IP, ONVIF ,RTSP ,P2P SMTP, HTTP, FTP, PPPoE and other Internet related protocols;
Specification
Model: BN-IP100WB | ||
Feature | Local Storage | TF card ,32GB |
P2P | Plug & Play,99% penetration rate, Easy to setup: | |
QR Code Scanning. | UID scan technology applied, easy to operate, and highly confidential. | |
System | Control protocol | ONVIF protocol |
Bit Rate | CBR/VBR, output bit rate range:128~4096kbps | |
Processor | Hi processor, built in ARM926 @Max. 440MHz and high-speed video co-processor | |
Video | Compression Format | H.264 baseline profile@levels:3.1/Motion-JPEG |
Frame rate | 30fps/25fps(720p) | |
Resolution | 720P(1280*720), VGA(640*480), QVGA(320*240) | |
Sensor | 1/4 720p Progressive CMOS sensor | |
Minimum illumination | 0.8Lux/F1.4(colourful model ),0.3Lux/F1.(B&W mode) | |
SNR | ≥39dB | |
Electronic shutter | 1/50s(1/60s)-1/100, 000s | |
CMOS | support AWB, AGC, BLC | |
Lens/viewing angle | 3.6mm/ F1.4/56.14 | |
Night vision | 12pcs 850nmΦ5mm LED,15m IR distance | |
Audio | Compression format | ADPCM/32kbps |
Input | Built-in 48dB microphone | |
Output | Built-in speaker 8Ω2W | |
P/T Network | P/T | Pan:355°,Tilt:120° |
Network Port | 10/100Mbps RJ45 port | |
Network Protocol | TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,RTSP,P2P,etc. | |
Online visitor | Support 4 online visitors simutaneoursly | |
WIFI | WIFI 802.11 b/g/n | |
Alarm | Input | Wireless input alarm sensor |
Motion detection | Support | |
Sound detection | Support | |
Alarm action 1 | Buzzer alarm | |
Alarm action 2 | Taking picture and sending email or FTP to upload video | |
Physical | Body material | ABS Plastic, indoor use |
Power input | DC 5V 2A | |
Temperature | -10~50 °C | |
Package size | 179×120×200mm (L×W×H) | |
Weight | Gross Weight :755g(Note: in kind prevail) | |
