Wireless Network Camera Networkcamera Wireless Camera

Name: Wireless Network Camera Networkcamera Wireless Camera
Brand: Aoya
SKU: 119487771

US$ 38 - 48 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Aoya

Model Number:

C168

Shenzhen Aoya Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Aoya

Model Number C168

Type Digital Camera

Style Box Camera

Sensor Other, CMOS, CMOS,1/4'' 1.0 Megapixel CMOS

Technology NetWork

Special Features Other, Mobile alarm

Product Description

wireless network camera networkcamera wireless camera

>Dual stream H.264 1/4" Color CMOS Sensor 1.0 Megapixel

>Resolution: 720P: 1280*720@30fps

>12* IR LEDs make 15m night vision.

>Suport QR Code Scanning.

> Build-in TF card slot, Max 32GB

>Build-in Microphone & Speaker, supporting two-way audio intercom

>Alarm push technology-Compatible with a variety of wireless smoke/gas detector,door magnetic

Support 64 alarm input and max. 8 zones. Camera gives alarm when alarm triggered

>P2P(Plug&Play)technology,penetration degree can be 99%,applicable toany

>Pan/Tilt control: Pan:355°& Tilt:120°

>Mobile Monitor: iPhone(APP Store),Android

>Wi-Fi compliant with wireless standards IEEE 802.11b/g/n

>support TCP/IP, ONVIF ,RTSP ,P2P SMTP, HTTP, FTP, PPPoE and other Internet related protocols;

Specification

Model: BN-IP100WB
Feature	Local Storage	TF card ,32GB
	P2P	Plug & Play,99% penetration rate, Easy to setup:
	QR Code Scanning.	UID scan technology applied, easy to operate, and highly confidential.
System	Control protocol	ONVIF protocol
	Bit Rate	CBR/VBR, output bit rate range:128~4096kbps
	Processor	Hi processor, built in ARM926 @Max. 440MHz and high-speed video co-processor
Video	Compression Format	H.264 baseline profile@levels:3.1/Motion-JPEG
	Frame rate	30fps/25fps(720p)
	Resolution	720P(1280720), VGA(640480), QVGA(320*240)
	Sensor	1/4 720p Progressive CMOS sensor
	Minimum illumination	0.8Lux/F1.4(colourful model ),0.3Lux/F1.(B&W mode)
	SNR	≥39dB
	Electronic shutter	1/50s(1/60s)-1/100, 000s
	CMOS	support AWB, AGC, BLC
	Lens/viewing angle	3.6mm/ F1.4/56.14
	Night vision	12pcs 850nmΦ5mm LED,15m IR distance
Audio	Compression format	ADPCM/32kbps
	Input	Built-in 48dB microphone
	Output	Built-in speaker 8Ω2W
P/T Network	P/T	Pan:355°,Tilt:120°
	Network Port	10/100Mbps RJ45 port
	Network Protocol	TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,RTSP,P2P,etc.
	Online visitor	Support 4 online visitors simutaneoursly
	WIFI	WIFI 802.11 b/g/n
Alarm	Input	Wireless input alarm sensor
	Motion detection	Support
	Sound detection	Support
	Alarm action 1	Buzzer alarm
	Alarm action 2	Taking picture and sending email or FTP to upload video
Physical	Body material	ABS Plastic, indoor use
	Power input	DC 5V 2A
	Temperature	-10~50 °C
	Package size	179×120×200mm (L×W×H)
	Weight	Gross Weight :500g(Note: in kind prevail)
