CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller

CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller thumbnail-1
CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller thumbnail-2
CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller thumbnail-3
CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller photo-1
CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller photo-2
CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller photo-3
US$ 24.2 - 29.2 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
YIGAO
Model Number:
T1000s
Contact Supplier Request Quote Chat Now
Shenzhen Guangjiang Yigao AD. LED Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name YIGAO
Model Number T1000s
Type Manual Switch
Max. Load Power 576W
Voltage 220V

CE And Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller

From YiGao company, the China LED factory since 1995



1.32—256 Gray,Support software Gamma correction.

2.Support the rules and special-shaped handle.

3.Single-port output,can support 2048 lights.

4.Off-line(SD Card) control, play back content stored in the SD card.

5.Rf Rgb Controller store a maximum of 16 programs,copy multiple files to the SD card in order,

after formatting the SD card as “FAT” format.

6.The program must be named in orders . Ex. :00_1.led, 01_1.led, 02_1.led.

7.Compatible with single line or double line chips.

NOTE:

1. When T-1000S Rf Rgb Controller less than 512 pixels the frame rate can reach 30fps. When T-1000S control more than 512 pixels the frame rate will slow down automatically.

2. T-1000S Rf Rgb Controller must use the new software LedEdit 2012.



Rf Rgb Controller product photo show



CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller





CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller



CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller







CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller

Rf Rgb Controller Product details

CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf ControllerCE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller

Rf Rgb Controller definition of buttons:


Buttons

Meaning

SAVE SET

Save Settings (to save current settings file and the playback speed )

MODE

Change programs

SPEED+

Speed up

Press speed+ and speed- on the same time the program will play circularly.

SPEED-

Speed down







DC5V

+5V power input

GND

Power GND input

7.5-24V

+7.5-24V power input

POWER

Power indicator

ERROR

Error indicator

SD CARD

SD card slot





    TTL signal(245/spi signal):               RS485 signal.



CLK

Clock signal

B

Signal A / DMX+

DAT

Data signal

A

Signal B / DMX-

GND

Signal ground

GND

Signal ground







NOTE:For the TTL(SPI) signal, the controller signal ground must connect to the LED ground directly.



CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller

 Rf Rgb Controller Connecting

CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller



1.Multiple T-1000S Rf Rgb Controller can be cascaded together and work synchronous.

2.T-1000S one TTL(SPI) signal and one RS485 signal port output,can control 2048 pixels;

3.When the chip for LED is single line chip just with data, then just need to be connected with DAT and GND of the controller.

If the chip for LED is double line chip with DAT and CLK, then need to be connected with DAT, CLK, and GND of the controller.

4.If you need to use RS485 signal you need to connect controller A with LED A (DMX+), controller B with LED B(DMX-),

5.When you need to built a new project the Rf Rgb Controller type for the software is:T-1000-IC model.



CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller
  Rf Rgb Controller certifications
CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf ControllerCE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller



CE and Rohs Dc5-24v Mutil-fuction Programmable Rgb Led Rf Controller
