50mm 24v Industrial Radiator Fan

50mm 24v Industrial Radiator Fan thumbnail-1
50mm 24v Industrial Radiator Fan photo-1
US$ 2 - 5 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
DC
Mounting:
Other, cooling fan
Blade Material:
Plastic
Contact Supplier Request Quote Chat Now
Shenzhen Topfan Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type DC
Mounting Other, cooling fan
Blade Material Plastic
Place of Origin Guangdong, China
Brand Name OEM
Model Number YM2405PTS(B)1
Voltage 5V,12V,24V
Power 0.95~4.08W
Air Volume 7.5-7.48CFM
Speed 3000-6000rpm
Certification CE, UL, ROHS, Other, UL, CE, CE, UL, ROHS, ISO9000, UL ,CE, RoHS, TUV
After-sales Service Provided No overseas service provided

Specifications

2 inch DC cooling fan
1.High performance
2.Good waterproof and Oil proof
3.Low temperature rise
4.low noise and long life

 50 X 50 X 25mm dc 5v/12v/24v brushless cooling fan



General Specifications:

Frame

plastic(UL94v-0)

Impeller

plastic(UL94v-0)

Bearing type

Dual Ball Bearing

Leadwire

UL1007AWG#24 or Equivalent (+):Red(-):Black

Motor

Impedance Protected and Reverse Polarity Protected

Voltage

5V,12V,24V



Expected Life:

1.Ball Bearing 50,000 hours(40°c)

2.Sleeve Bearing 30,000 hours(40°c)



Allowable Ambient Temperature Range

1.-10°c~+70°c (Operating)

2.-40°c~+70°c (Storage)

3.(non-condensing environment)



Specifications:



Size(mm) Model Rated voltage (v)      Operating Voltage Range(v)    Current amp    (Amp) Rated Input Power  Watt Speed (rpm)  Max air Flow (CFM) Max air Flow (m3/min) Max Static Pressure (Inch-H2o) Noise Leve (dB-A) Weight  (g)
 50 X 50 X 25 YM0505PTS(B)1 5 3.5 to 5.5 0.24 1.20 4000 11.13 0.32 0.10 27 35
  YM0505PTS(B)2 5 3.5 to 5.5 0.19 0.95 3000 7.50 0.21 0.06 23 35
  YM1205PTS(B)1 12 7.0 to 13.8 0.22 2.64 6000 17.83 0.50 0.23 37 35
  YM1205PTS(B)2 12 7.0 to 13.8 0.16 1.92 5000 14.43 0.41 0.16 31 35
  YM1205PTS(B)3 12 7.0 to 13.8 0.12 1.44 4000 11.13 0.32 0.10 27 35
  YM1205PTS(B)3 12 7.0 to 13.8 0.08 0.96 3000 7.50 0.21 0.06 23 35
  YM2405PTS(B)1 24 14.0 to 27.6 0.17 4.08 6000 17.83 0.50 0.23 37 35
  YM2405PTS(B)2 24 14.0 to 27.6 0.11 2.64 5000 14.43 0.41 0.16 31 35
  YM2405PTS(B)3 24 14.0 to 27.6 0.09 2.16 4000 11.13 0.32 0.10 27 35



50mm 24v industrial radiator fan50mm 24v industrial radiator fan
