Home > Industrial Equipment & Components > Ventilation Equipment > Blowers > Small Turbo Exhaust Fan 12v 24v 40*52*10mm

Small Turbo Exhaust Fan 12v 24v 40*52*10mm

Small Turbo Exhaust Fan 12v 24v 40*52*10mm thumbnail-1
Small Turbo Exhaust Fan 12v 24v 40*52*10mm thumbnail-2
Small Turbo Exhaust Fan 12v 24v 40*52*10mm photo-1
Small Turbo Exhaust Fan 12v 24v 40*52*10mm photo-2
US$ 2 - 6 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
DC
Blade Material:
Plastic
Mounting:
Other, cooling fan
Contact Supplier Request Quote Chat Now
Shenzhen Topfan Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type DC
Blade Material Plastic
Mounting Other, cooling fan
Place of Origin Guangdong, China
Brand Name MX/OEM/ODM
Model Number MX4010GB(S)U1
Power 2.16W
Voltage 5V/12V/24V
Air Volume 3.06CFM
Speed 5500RPM
Certification CCC, CE, ROHS, UL, Other, UL, CE, CCC, CE, ROHS, UL, ISO9000, UL ,CE, RoHS, TUV

Industrial turbo exhaust fan 12v 24v 40*52*10mm




Product Description



General Specifications:



Frame

plastic(UL94v-0)

Impeller

plastic(UL94v-0)

Bearing type

Sleeve Bearing and Dual Ball Bearing

Leadwire

UL1571AWG#28 or Equivalent (+):Red(-):Black

Motor

Impedance Protected and Reverse Polarity Protected



Expected life:

1.ball bearing 50,000 hours(40 °c)

2.sleeve bearing 30,000 hours(40 °c)



Allowable ambient temperature range:

1.-10°c~+70°c (Operating)

2.-40°c~+70°c (Storage)

3.(non-condensing environment)



Specifications:



Model Bearing Type Rated Voltage Operating Voltage Input Current Input  Power Speed Max Air Flow  Max Static Pressure Noise Weight
Part No. B.S VDC VDC Amp Watt RPM CFM m3/min Inch-H2O pa dB-A g
MX4010GB(S)H5 B.S 5 3.5-5.5 0.23 1.15 5000 3.06 0.09 0.29 72.57 27 21
MX4010GB(S)M5 B.S 5 3.5-5.5 0.20 1.00 4500 2.64 0.07 0.21 52.37 25 21
MX4010GB(S)L5 B.S 5 3.5-5.5 0.16 0.80 4000 2.23 0.06 0.15 37.85 23 21
MX4010GB(S)U1 B.S 12 7.0-13.8 0.18 2.16 5500 3.12 0.09 0.31 77.08 29 21
MX4010GB(S)H1 B.S 12 7.0-13.8 0.15 1.80 5000 3.06 0.09 0.29 72.57 27 21
MX4010GB(S)M1 B.S 12 7.0-13.8 0.12 1.44 4500 2.64 0.07 0.21 52.37 25 21
MX4010GB(S)L1 B.S 12 7.0-13.8 0.10 1.20 4000 2.23 0.06 0.15 37.85 23 21
MX4010GB(S)U2 B.S 24 14.0-27.6 0.10 2.40 5500 3.12 0.09 0.31 77.08 29 21
MX4010GB(S)H2 B.S 24 14.0-27.6 0.07 1.68 5000 3.06 0.09 0.29 72.57 27 21
MX4010GB(S)M2 B.S 24 14.0-27.6 0.05 1.20 4500 2.64 0.07 0.21 52.37 25 21
MX4010GB(S)L2 B.S 24 14.0-27.6 0.03 0.72 4000 2.23 0.06 0.15 37.85 23 21










Small turbo exhaust fan 12v 24v 40*52*10mmSmall turbo exhaust fan 12v 24v 40*52*10mm


Company Information



Small turbo exhaust fan 12v 24v 40*52*10mm

Small turbo exhaust fan 12v 24v 40*52*10mm


Packaging & Shipping

Small turbo exhaust fan 12v 24v 40*52*10mm
