CIMC RUIJIANG is a special vehicle manufacturer that belongs to CIMC group and is located in Wuhu, Anhui province. The company possesses assets worth of 160 million US Dollars with total area of 330000 square meters; the plant area encompasses approximately 90000 square meters. We have international advanced production lines for concrete mixers, powder tankers, liquid tank trucks, aluminum alloy tank trucks, dump trucks, semi-trailers. The company produces more than 300 varieties of special vehicles of more than 10 series. CIMC RUIJIANG has won a lot of titles: “National Hi-tech Enterprise”, “National Torch Plan Enterprise”, “Anhui Province Technical Centre”, “Anhui Province Top 100 Enterprises”, “The Famous Brand of Anhui Province”, “Anhui Province Quality Award” etc. and owns more than 600 national patents. Following the business philosophy of the company which is“your partner for modern transportation”, the sales network of CIMC RUIJIANG has been covering China mainland and global markets including Asia, Africa, South America, East Europe, etc. Now the company is a leader of special vehicle manufacturers in China. To enhance company’s management level CIMC RUIJIANG implemented TS16949, TPS quality management system, internal control system etc. The company adopted international advanced equipments and improved the automation and informatization in manufacturing process to guarantee the quality of products.
| 60M3 3 axle bulk cement powder tank truck semi-trailer | |||||||||
| Item | Uint | Parameter | |||||||
| Dimension | Overall length | mm | 12750 | ||||||
| Overall width | mm | 2,500 | |||||||
| Overall height | mm | 3,995 | |||||||
| Landing leg setting | mm | 2,500 | |||||||
| King pin setting | mm | 16,200 | |||||||
| King pin plate height | mm | 1,303 | |||||||
| Wheelspan | mm | 7500+1310+1310 | |||||||
| Axle spacing | mm | 1,310 | |||||||
| Running gear | Axle | Square axle,150X150mm.(FUWA 16T capacity | |||||||
| Wheel | 8.5-20,10 holes steel Disc wheel,13Pcs. | ||||||||
| Tire | 1100R-20,11.00R20,12R22.5 13Pcs | ||||||||
| King Pin | 2 " or 3.5" king pin, JOST | ||||||||
| Landing leg | Two speed manual operation type with sand shoe | ||||||||
| Suspension | Undermount tri-axle suspension with equalizer; 10-Leaf Spring. | ||||||||
| Brake | Dual line pneumatic brake system | ||||||||
| Parking brake | Type 30/30 spring brake system on two axles | ||||||||
| Structural weight ratting | Loading capacity | m3 | 50 | ||||||
| Tare weight | kg | 12000 | |||||||
| Pay load | kg | 28000 | |||||||
| G,V,W,R | kg | 40000 | |||||||
| Diesel engine | 4102 Made in China, (44Kw,2000r/Min) | ||||||||
| Air compressor | 10m3/min Made in China | ||||||||
| Pneumatic system | Mounted at the front of trailer | ||||||||
| Electrical | Voltage | 24 volt | Side Marker Lamp | Amber | |||||
| Receptacle | 7 way | Rear Lamp | Red | ||||||
| Front Marker Lamp | White | Turn Signal Lamp | Amber | ||||||
| Tank shell | Q345 4mm-5mm thickness | ||||||||
| Dished ends | Q235,5mm thickness or Q345,4 thickness | ||||||||
| Pipe material | Carbon steel | ||||||||
| Discharging Hose Diameter | 4” | ||||||||
| Discharging valve | 5” butterfly valve | ||||||||
| Discharging Hose Length | 7,000 mm | ||||||||
| Hose quick coupling | 4” female quick coupling | ||||||||
| Discharging capacity | ≥1m3/min | ||||||||
| Working pressure | 0.2 Mpa | ||||||||
| Test pressure | 0.3 Mpa | ||||||||
| Manhole | three | ||||||||
| MAX. Horizontal Discharging Distance | 5,000 mm | ||||||||
| MAX. Vertical Discharging Distance : | 15,000 mm | ||||||||
