Mppt 12v/24v 20 Amp Solar Charge Controller With High Quality-MPPT-20D

Mppt 12v/24v 20 Amp Solar Charge Controller With High Quality-MPPT-20D thumbnail-1
Mppt 12v/24v 20 Amp Solar Charge Controller With High Quality-MPPT-20D photo-1
Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
CARSPA
Model Number:
MPPT-20AD
Contact Supplier Request Quote Chat Now
Zhejiang Carspa New Energy Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo or shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name CARSPA
Model Number MPPT-20AD
Application Solar System Controller
Rated Voltage 48V
Maximum Current 20A

mppt 12v/24v 20 amp solar charge controller with high quality-MPPT-20D

mppt 12v/24v 20 amp solar charge controller with high quality-MPPT-20D

Specifications

intelligent solar charge controller, solar charge controller, PV controller,MPPT

MPPT advantage:
Maximum Power Point Tracking (MPPT in short) system is a system which allows PV panels to outputs more Power by adjusting working condition of the electrical module. In Figure1 A indicates that the ordinary controller, which makes PV battery work on 12V ,only outputs a power point of 53W (a general power point), B indicates that MPPT controller makes PV battery always work at the maximum power point, thus outputs the power point of 75W (the maximum power point).

Product features:
Applicable to various types of batteries,
MPPT function
Temperature sensor battery charging compensation
Overload protection (automatic restoration)
Overcharge protection
Short circuit protection (automatic restoration)
Thunder protection
Reverse discharge protection
Reverse polarity connection protection (automatic restoration)
Under voltage protection

MPPT principle:
The maximum power point is mainly affected by the ambient temperature and the intensity of sunshine. The intensity of sunshine being constant, the maximum output power decreases with the rise of the temperature. The temperature being constant, when the sunshine intensifies, the open circuit voltage of PV battery basically keeps unchanged. But the short circuit current increases substantially, thus the maximum output power increases substantially.

This MPPT solar controller can intelligently regulate the working voltage of solar panels, letting the solar panels always work at Maximum Power Point of V-A curve. Compared with ordinary solar controller, this MPPT controller can increase the efficiency of PV modules by about 30%.

However, due to many different factors, such as the difference in solar panel making, the change the Sun luminance, change in temperature, the efficiency of the controller etc., the actually available increased rate is 10%-30%.
Model
                                       MPPT-20A
Rated Voltage
                                   12V / 24V / 48V
Max Load current
                                              20A
Input voltage range
                      12V~40V / 24V~80V / 48V~110V
Length≤1m
Charge loop drop
                                           <0.25V
Length≤1m
Discharge loop drop
                                           <0.05V
Over voltage protection
                                     17V / 34V / 68V
Full charge cut
                                   13.7V / 27.4V / 54.8V
Low voltage cut
                            10.5V~11V / 21V~22V / 42V~43V
Temperature compensation
                                       -3mv/°C/cell
No load loss
                                           ≤10mA
Max wire area
                                           4 mm2
Ambient temperature
                                    -25°C——+55°C
N.W./pcs
                                           0.74kg
Pcs/ ctn
                                            20pcs
G.W./ctn
                                           15.5kg
